• Model NO.：CSK-15,18
• Material：Stainless Steel 304
• Transport Package：Seaworthy Ply-Wooden Package
• Trademark：Helper
• Origin：Hebei, China
• Production Capacity：30 Sets,Year

Basic Info.

Model NO. CSK-15/18 Material Stainless Steel 304 Transport Package Seaworthy Ply-Wooden Package Trademark Helper Origin Hebei, China Production Capacity 30 Sets/Year

Product Description

Automatic Dual Clipper Machine for Ham/Polony/Sausage

The Automatic Dual Clipper Machine is driven by servomotor with compact structure and reliable transmission.
The machine body, main parts and transmission parts, are all made of excellent aluminum alloy and stainless steel.
The integrated mechanical property of machine can Satisfy your different requirements.

Feature of Automatic Dual Clipper Machine:
*Elegant Great Wall Clips make high grade appearance for clipping
*Clip speed: 0-120times adjustable
*Flat width of casing available: 30mm-120mm
*Cut knife is driven pneumatically
Main electronic components from Japan or Europe.
Voltage and Current is changeable according to customer requests.

Clip available Speed of clipping(times) Motor power(kw) Power supply(v) Great Wall Type 0-120adjustable 3.5 single-phase alternating current220± 10% (servomotor) three-phases alternating current380± 10% (electromagnetical onoff)

Air source(Mpa) Casing available(mm ) Air consumption(m 3 ) Dimension(mm) work presure0.5-0.6(for cutter) flat diameter is from30-120 0.0064(for cutter) 760× 750× 1770
