• Model NO.：TQLM125
• Condition：New
• Customized：Customized
• Output(T/H)：32,10
• Power(Kw)：0.75
• Air Volume(M^3/H)：3600
• Net Weighe(Kg)：800
• Transport Package：Wooden Box Package
• Specification：3100*2250*1700
• Trademark：pinyang
• Origin：Hubei China
• HS Code：8437000000
• Production Capacity：6-12t,H

Basic Info.

Model NO. TQLM125 Condition New Customized Customized Output(T/H) 32/10 Power(Kw) 0.75 Air Volume(M^3/H) 3600 Net Weighe(Kg) 800 Transport Package Wooden Box Package Specification 3100*2250*1700 Trademark pinyang Origin Hubei China HS Code 8437000000 Production Capacity 6-12t/H

Product Description

Equipment with screen surface of certain specification, TQLM rotary cleaning sieve clears out large, tiny and light impurties in grain during plane rotary movement. According to separating the demand for different supplies, this cleaning machine can be adjusted rotational speed and lay perticular stress on resultant, to change its amplitude, thus it reach the best result.



Model	TQLM80	TQLM100	TQLM125	TQLM150
Capacity(t/h)	20/6.4	25/8	32/10	38/12
Air volume (m^3/h)	2400	3000	3600	5700
Power(kw)	0.75	0.75	0.75	0.75
Dimension(L*W*H)	2020*1200*1460	2020*1400*1460	2020*1650*1460	2020*1900*1460
Weight(kg)	600	700	800	950
C*l2	750*180	960*180	1200*180	1450*180
A	1100	1300	1550	1800
H1	1100	1100	1100	1100
B*L3	700*150	900*150	1150*150	1150*150
