• Model NO.：FL-150 250 350 500
• Specification：GMP ISO CE
• Trademark：XD
• Origin：Jiangyin, Jiangsu, China(Mainland)
• HS Code：8479820090
• Production Capacity：300 Sets,Year

Basic Info.

Model NO. FL-150 250 350 500 Specification GMP ISO CE Trademark XD Origin Jiangyin, Jiangsu, China(Mainland) HS Code 8479820090 Production Capacity 300 Sets/Year

Product Description

Coriander Spice Powder Grinder Grinding Machine

1.. Introduction

(1) The machine uses the relative movement between the active fluted disc and the fixed fluted disc to impact, grind and crush the target materials.

(2) The size of granules can be achieved by changing of the screen.

(3) The machine has the fea-tures of easy structure. Solid, stable running and good efficiency.

(4) The crushed ma-terial is discharged directly from the grinding chamber of the main frame.

(5) In addi-tion, the whole machine is, made of stainless steel, with smooth inside walls to and avoid powder accumulation on the inside walls.

(6) The machine is widely applied in those such as pharmaceutical, chemical and foodstuff industries etc.

(7) The machine are in accordance with national require-ment, achieving "GMP" standard.

Working method

(1) The machine uses the wind wheel type highspeed rotary cutters and the fixed cutters to crush, mill and shear raw material, which is accompanied by strong airflow inside of the chamber to bring out the heat with the finished products through the screen.

(2) The size of granules can be achieved by changing of the sieve.

Model	Model 150	Model250	Model 350	Model500
Capacity(kg/h)	20-80	30-200	50-300	80-500
Size of input granules(mm)	< 10	< 10	< 12	< 15
Size of output granules	12-120	12-120	12-120	12-120
Motor power(kw)	2.2	5.5	7.5	11
Speed of principal (axisr/mim)	3000	2900	2900	2800
Weight(kg)	185	195	200	320
Overall size (L× W× H)(mm)	550× 420 × 1400	770× 750 × 1500	870× 750 × 1608	960× 750 × 1750
