2015 Vacuum Sausage Filling Machine (ZKG-6500 with lifter)
Shijiazhuang Helper Food Machinery Co., Ltd.- Transport Package：Seaworthy Wooden Case
- Trademark：Helper
- Origin：Hebei, China
Base Info
- Model NO.：ZKG-6500
- Production Capacity：50sets,Month
Description
Basic Info.
Model NO. ZKG-6500 Production Capacity 50sets/MonthProduct Description
Vacuum sausage filling machine with lifter ZKG-65001. The filling and twisting are driven by servomotor.
2. The human-machine interface, servo motor, reducer and PLC controller and vacuum pump are all imported.
3. The lifting device save the labour.
4. The portioning error of meat paste is within+-1.5g, and meat block within +-3G.
5. The automatic twisting is applicable for various natural casing, collagen casing and smoked casing.
6. Working with clipping machine realized automatic production line.
7. The twisting speed is stepless adjusted.
If you have interest, contact with person Albert Lee pls.
| Model | Portioning Range(g) | Filling Capacity(kg/h) | Hopper Capacity(L) | Power(kw) | Voltage(V) | N. W(kg) | Dimension(mm) |
| ZKG-3500 | 5-9999 | 3500 | 220 | 5.3 | 380 | 600 | 1400*970*2100 |
| ZKG-6500 | 5-9999 | 6500 | 220 | 6.1 | 380 | 850 | 1400*1000*2150 |
| ZKG-9000 | 5-9999 | 9000 | 220 | 8.1 | 380 | 1100 | 1450*1050*2100 |
You are always welcome to visit our factory!
