• Model NO.：KQ
• Voltage：380V
• Customized：Customized
• Name：Heating Mixing Fermentation Holding Buffer Tank
• Agitator Speed：36rpm, 48rpm, 960rpm,2900rpm
• Stainless Steel Degree：Stainless Steel 304,316
• Heating and Mixing Tank：for Heating and Mixing Liquid, Liquid and Powder
• Storage Tank：Aseptic Storage Tank with Manhole
• Delivery：10 Days
• Packing：Wooden Box
• OEM：Yes
• Factory：Shanghai China
• Working Life：More Than 10 Years
• Motor Brand：Siemens ,ABB ,China Brand
• Insulation Wall：Rock Wool , Polyurethane Foam
• Surface Treatment：Inside Mirror and Outside Matt
• Speed of Mixer：36rpm ,48rpm,2900rpm
• Accessories：Make It to Your Order .
• Transport Package：Standard Export Wooden Box
• Specification：ISO
• Trademark：KQ
• Origin：Shanghai China
• HS Code：8479820090
• Production Capacity：200L To30000L

Basic Info.

Model NO. KQ Voltage 380V Customized Customized Name Heating Mixing Fermentation Holding Buffer Tank Agitator Speed 36rpm, 48rpm, 960rpm,2900rpm Stainless Steel Degree Stainless Steel 304/316 Heating and Mixing Tank for Heating and Mixing Liquid, Liquid and Powder Storage Tank Aseptic Storage Tank with Manhole Delivery 10 Days Packing Wooden Box OEM Yes Factory Shanghai China Working Life More Than 10 Years Motor Brand Siemens /ABB /China Brand Insulation Wall Rock Wool / Polyurethane Foam Surface Treatment Inside Mirror and Outside Matt Speed of Mixer 36rpm /48rpm/2900rpm Accessories Make It to Your Order . Transport Package Standard Export Wooden Box Specification ISO Trademark KQ Origin Shanghai China HS Code 8479820090 Production Capacity 200L To30000L

Product Description

  Heating Mixing Fermentation Holding Buffer Tank For Food Industry .

1

sugar mixing tank

TankCapacity(L)	200, SS304	300, SS304	500, SS304	1000,SS304
REV	36r/min	36r/min	36r/min	36r/min
Electric motor of the agitator	0.55KW,380v,50hz	0.75KW,380v,50hz	0.75KW,380v,50hz	1.1KW,380v,50hz
Heating Area(M2)	0.9	1.1	1.9	4.5
Material Input/output(DN MM)	38	38	38	50
OUTSIDE DEMENSION(L*W*H)MM	900*900*1600	1000*1000*1500	1100*1100*1700	1400*1400*1750
GROSS WEIGHT(KGS)	150	200	300	450

Stainless Steel Milk Yogurt Fermentation Tank For Milk Factory
Material: Ss304
* Type: With Jacket and insulation
* Internal shell thickness: 3 mm
* Jacket thickness: 3 mm
*PU INSULATION WALL: 50MM
* Outer shell thickness: 1.5 mm
* Appearance: Ellipsoidal head top and down manhole and pipe will be as the picture you sent to us
* Accessories:
  Heating Mixing Fermentation Holding Buffer Tank For Food Industry .
