• Model NO.：YZLXQ120-8
• Condition：New
• Customized：Non-Customized
• Daily Processing Capacity：6tons,24hs
• Dimension(L*W*H)：1948*1522*1915mm
• Power：11-15kw
• Weight：1115kgs
• Transport Package：Fumigated Wooden Packing, or as Customers′ Request
• Specification：ISO, BV, SGS
• Trademark：GUANGXIN
• Origin：Sichuan, China
• HS Code：84792000
• Production Capacity：400pieces,Month

Basic Info.

Model NO. YZLXQ120-8 Condition New Customized Non-Customized Daily Processing Capacity 6tons/24hs Dimension(L*W*H) 1948*1522*1915mm Power 11-15kw Weight 1115kgs Transport Package Fumigated Wooden Packing, or as Customers′ Request Specification ISO, BV, SGS Trademark GUANGXIN Origin Sichuan, China HS Code 84792000 Production Capacity 400pieces/Month

Product Description

Characteristc
YZLXQ120-8 integrated sunflower oil press with air pressure filter is one of our integrated models. It has pre-heating, squeezing and filtrating functions in one. The oil in the seeds can be extracted out only by one time and then flow to the air compressor filtration machine to be purified right away. After that, the oil is clean and edible. It is an ideal equipment for oil refinery and small oil mill use.


Qualification Standard:
Our oil press strictly conforms to GB/T9793.1-19999 of the People's Republic of China and has been ISO, BV, CQC and SGS certificated.

After-Sale Service:

1. We supply spare all year around.
2. We supply technical solutions and helps at any time.


Applicable oil plants:

Suitable for rapeseeds, cotton seeds, soybean, shelled peanut, flax seeds, sunflower seeds and palm kernel, and many other oil material not listed here.

Quality Standard:
Conform to JB/T9793· 1-1999 of The People's Republic of China & ISO9001: 2008.


Warranty terms:
Free replacement of main body in 12 months from the date of purchasing if ther are quality problem.

Model	YZLXQ95	YZLXQ10	YZLXQ10-6/8/9	YZLXQ130
Processing Capacity (t/24h)	≥3.5	≥3.5	≥4.5	≥8.0
Oil Content of Dry Cakes	≤8.0	≤8.0	≤8.0	≤8.0
Main Electromotor Power (KW)	7.5 or 11	7.5 or 11	11	15
Pump Electromotor Power (KW)	1.5	1.5	1.5	1.5
Temperature Control Power (KW)	3.6	3.6	3.6	4
Measurement (mm)	1790×1520×1915	1790×1520×1915	1890×1520×1915	2050×1522×1915
Spiral Axes Rotate Speed (r/min)	32-40	32-40	32-40	34
Weight (KG)	1023	1023	1075	1320
