Snack Chocolate Making Machine for Sale Made in China
NINGBO HUADONG MACHINERY CO., LTD.- Certification:CE, ISO9001
- Power Source:Electric
- Process:Concentration and Dry
- Automatic Grade:Semi-Automatic
- Application:Chocolate
- Customized:Non-Customized
Base Info
- Model NO.:QHZ
- Material:Stainless Steel,Carbon Steel
- After-Sales Service Provided:Engineers Available to Service Machinery Overseas
- Warranty:1 Year
- Power:380V 50Hz
- Transport Package:Wood Case
- Trademark:Huadong
- Origin:Zhejiang, China (Mainland)
- Production Capacity:10
Description
Basic Info.
Model NO. QHZ Material Stainless Steel/Carbon Steel After-Sales Service Provided Engineers Available to Service Machinery Overseas Warranty 1 Year Power 380V 50Hz Transport Package Wood Case Trademark Huadong Origin Zhejiang, China (Mainland) Production Capacity 10Product Description
Snack Chocolate Making Machine for sale made in China
Servo motor drives the entire depositor full range of movement, can produce multi-color, a variety of shapes, a variety of pattern chocolate
What is a one-time large sandwich pouring technology:
Pouring head in a pouring, according to the trajectory of the chocolate shape to change the casting volume and speed in order to achieve a more uniform chocolate shell thickness, the
sandwich to maximize the amount.
Parameters | SJZ 48 Depositor | SJZ 72 Depositor | SJZ 96 |
Mode | 3D depositor | 3D depositor | 3D depositor |
Output | 1.6 Tons/ 8hr | 2.5 Tons/ 8hr | 3.5 Tons/ 8hr |
Capacity | 4-12trays/min | 8-12trays/min | 8-12trays/min |
Precision | ±2% | Precision | ±2% |
Piston amount, diameter | 2X48,Φ10mm | 2X72,Φ10mm | 2X96,Φ10mm |
Servo motor amount | 5 | 5 | 5 |
Moving axis | X,Y,Z | X,Y,Z | X,Y,Z |
Moving range | 90mm | 90mm | 90mm |
Power | 5kw | 6kw | 6kw |
Compress air | 0.8m³/min, 0.8MPA | 0.8m³/min, 0.8MPA | 0.8m³/min, 0.8MPA |
Size | 1632*2087*2000mm | 1632*2087*2000mm | 1632*2087*2000mm |
Weight | 1550kg | 1600kg | 1650kg |
Type | Mould speed (piece/min) | Centerfill % |
Multicolor (one depositor do two color) | 4-5 | ≤80 |
Multicolor (one depositor do one color) | 8-10 | ≤80 |
3D one shot chocolate | 8-10 | ≤80 |
2D chocolate | 8-12 | ≤80 |
Spraying two color chocolate | 8-10 | ≤80 |
Detail Show
