• Model NO.：KQ100L-30000L
• Name and Description：Large Meat Kettle Soup Kettle Cooking Kettle Jack
• Double Jacketed Kettle：Heating and Mixing
• Jacket Kettle Capacity：100L to 1000L
• Mixer：Scrapper Mixer, Normal Mixer
• Kettle Material：Stainless Steel 304,316,316L
• Temperature：Above 90degree
• Kettle Type：Vertical , Tilting
• Jacket Kettle：Heating by Electricity, Steam
• Customized Kettle：Heated by Steam,. Gas, Electricity
• Kettle with Mixer：Heating ,Mixing , Cooking,Homogenizing
• Transport Package：Standard Export Wooden Box
• Specification：ISO
• Trademark：KQ
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：2000set ,Year

0 liter steam jacketed cooking kettle factory Suitable MaterialJacketed  Kettle  is applied widely for the processing such products as:
1. candy, medicine, dairy, alcohol, cake, beverage, sweet, meat, cans,
2.boil water, cook, and stew, boil porridge etc in great scale dinning-room or eatery Steam jacketed kettle factory  Characteristics1. Big heating area;
2. High heating effective;
3. Uniform heating;
4. Fast heating speed, short liquid material boiling time;
50Litres to 1000Litres    Electric/Steam Heating Jacket Kettle/Large Jacket Cooking Kettle/jacket kettle
Tilting jacketed kettle boiler vessel, stainless steel gas/electric/steam jacket kettleINDUSTRY JACKET KETTLE, ELECTRIC HEATING JACKET KETTLE, STEAM HEATING JACKET KETTLE
stainless steel electric/steam/gas heating jacket kettle
Materials are all sanitary stainless steel 304 or 316L .
Humanized structure design and easy to operate .
Transition area of interior wall on tank adopts arc for transition to ensure no dead comer of sanitation .
Configuration of tank :
Quick open manhole .
Various types of CIP cleaners .
Fly and insect resistant sanitary breathing cover .
Adjustable triangular bracket .
Dismountable materials input pipe assembly .
Thermometer (According to customer requirements ).
Ladder (According to customer requirements).
Paddle blender .
Liquid level meter and lever controller (According to customer requirements) .
Eddy-proof board .
Overall Dimension for stainless steel  jacket kettle
Technology data :

	KQ50	KQ100		KQ150	KQ200	KQ300	KQ400	YT500
Capacity L	50	100		150	200	300	400	500
Jacketed pressure  Mpa	< 0.2
Evaporation capacity  kg/h	30		40	50	65	75	100	150
Heat area  m 2	0.3		0.45	0.76	1.0	1.15	1.44	1.90
Energy consumption  kg/h	30		44	55	72	90	110	165
N.W.  kg	100		190	210	230	320	360	485
LxWxH  mm	700X650X830		800X650X830	1350X650X1100	1400X700X1100	1450X800X1110	1500X850X1140	1600X900X1150




Large Meat Kettle Soup Kettle Cooking Kettle Jacket Butter Kettle .
