• Transport Package：Export Standard Wooden Case
• Model NO.：fta
• Trademark：chengli
• Origin：China
• Production Capacity：100kg Per Hour to 300ton Per Day

Basic Info.

Model NO. fta Transport Package Export Standard Wooden Case Trademark chengli Origin China Production Capacity 100kg Per Hour to 300ton Per Day

Product Description

100tpd wheat flour mill plant ,120tpd wheat flour mill plant,150ton wheat flour mill plant is an automatic production line with cleaning, stone removing, wheat threshing, dust removing, watering, grain cleaning and conveying. we can send our engineers to install it.
Henan grain and Oil Machinery Co., Ltd. is a professional grain manufacturer. It produces flour processing machinery, complete set of flour processing machinery, complete set of flour processing equipment, complete set of flour processing equipment and flour processing equipment, and adopts advanced flour processing technology.
120tpd wheat flour mill plant

1. Productive capacity: 120TPD
2. Final product: wheat flour and by product: bran
3. Packing standard: 10-25kg/bag or 25-50kg/bag for wheat flour, and

                 25-50kg/bag for bran

1. Final flour silos: 4 pcs with capacity of 25T respectively
2. Workshop: steel structure with dimension of (L*W*H) 21m*7m*11m
3. Power consumption: total 438.45kw, 65kwh for per ton wheat produce

For packing, we offer 2 sets packing machine, one for bran packing with capacity of 25-50kg/bag, one for flour packing with capacity of 10-25kg or 20-50kg/bag,
For 4 final product silos, we will prepare that well in our factory, and put it into pieces when shipping by containers. After reaching on your site, our engineers will assemble them together with flanges for sake of saving cost.


Technical index

1. Product types: te1 powder, TE2 powder, standard powder, secondary powder, bran:

2. Power consumption: about 60 kwh per ton of wheat

3. Teyi powder 65%, Teer powder 75%, standard powder 78%, secondary powder 5-15%, bran 22%

Finished product quality index

1. Flour fineness: 100-150 mesh

2. Magnetic metal content: no more than 0.003g/kg

3. Sediment concentration: no more than 0.002%


1. Moisture: storage type: 13.5-14.5%

150ton wheat flour mill plant is an automatic production line with cleaning, stone removing, wheat threshing, dust removing, watering, grain cleaning and conveying.
Process plan:
1. Processing capacity: 150 tons wheat / day



2. Equipped with power: 406 kw
3. Total cost of equipment:
4. Power consumption index: the power consumption per ton of wheat is about 55 degrees

Technical parameters of 150t wheat milling equipment:
Power (kw): 406
Equipment size (m): building type
Power consumption per ton: 40-45kw · H / T

Application and After-Sales Service
Warranty: one year after successful commissioning
Training: we offer free training of your workers

Expected installation time: we exist a full engineers team to you for finish all installing and commissioning work, 8 engineers needed
