• Model NO.：GD150BF
• Production Capacity：15sets,Year

Model

GD150BF

Output(kg/h)

150

Max lollipop weight

As per the lollipop size

speed

25~30 n/min

Steam consumption

Steam pressure

250kg/h, 0.5~0.8MPa

Compressed air consumption

Compressed air pressure

0.2m3/min,

0.4~0.6MPa

Electric power needed

18kW/380V

Total length(m)

15

Gross weight

3500 kgs



FEATURES:

The processing line is a compact unit which can continuously produce various kinds of lollipop under a strict sanitary condition. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.

1) PLC /computer process control available;

2) An LED touch panel for easy operating;

3) The standard production capacity is 100~150kg/h;

4) The main parts is made of hygienic Stainless Steel

5) Optional (mass) flowing controlled by Frequency inverters ;

6) In-line injection, dosing and pre-mixing techniques for the proportional addition of liquid;

7) Dosing pumps for the automatic injection of colors, flavors and acids;

8) Use  AUTOMATIC STEAM CONTROL SYSTEM instead of manual steam valve which controls a stable steam supply to the microfilm cooker;

9) "two-color stripe depositing", "two-color double layers depositing", "central filling", "clear" lollipop and etc. can be made.

10) Moulds can be made according to the lollipop samples provided by the customer.

CANDY SAMPLES:



COMMODITY: GD150BF FLAT LOLLIPOP Depositing Line

S/N

EQUIPMENT

SPEC.

UNIT

QTY

1

FIXED COOKER

200 L

PCS

1

2

GEAR PUMP

1

PCS

1

3

STORAGE TANK

200L

PCS

1

4

VACUUM MICROFILM COOKING UNIT with auto steam control system

4-1.MAIN MICROFILM COOKER (1)

4-2.PRE-HEATER(1)

4-3.VACUUM PUMP(1)

4-4.FEEDING PUMP with frequency inverter(1)

4-5.DISCHARGING PUMP

4-6.CONNECTING PIPES & VALVES(1set)

5-7.PLC CONTROLER(1)-MITSHUBISHI

150KGS/H

SET

1

5

LOLLIPOP DEPOSITING UNIT:

5-1.DEPOSITING MACHINE(1)

5-2 AUTO STICK PLACER

5-3 FLAVOR AND COLOR DOSING PUMPS(4)

5-4.INDUSTRIAL COOLING SYSTEM(1set)

5-5.FLAVOUR MIXER(2)

5-6.CONNECTING PIPES(1set)

5-7.PLC CONNECTING(1)

150KGS/H

SET

1

6

MOULDS

260PCS/SET

SET

1

Company Information
Know about TGMachine Go to TGMachine Choose TGMachine

• Present TGMachine

  Nowadays,TGMachine always stand in the leader position in food machinery innovation and developing.The factory area is more than 6000 square metres,including five modern workshop,over 100 employees and has CNC machine,computer controlled lathe etc..ln 2005,TGMachine has passed ISO9001 internatinal quality management system certification standards and most of the products proved by CE .TGMachine exported its products to East European,South America,Middle East,Southeast Asia etc..since 2000.Rely on high quality products and satisfying service TGMachine gains its good reputation and popularity.



• Service From TGMachine

  TGMachine provides not only good quality production lines for different kinds of confectionery production,but also the whole solution from marketing research,factory design,machinery installation and final production,packing design etc..We are happy to cooperate with the new investor in food industry or experienced manufacturers.For more solution or information, please contact us by visit our website: shinwei.en.made-in-china.com



• TGMachine's Customers Location Worldwide

Packaging & Shipping

Wooden Packing:



1. Product production is completed, by the quality inspection department to check
2. After inspection qualified, clean for whole machine
3. Packing:

    a. Inside the machine put desiccant

    b. Add 6 cm thick foam plate around the machine,Then, winding stretch film for reinforcement, and combined with bubble wrap

    c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4. Container: according to different products for reinforcement.

Our Services

After-Sale Service For Abroad Customers:



1. Free training of machine installation, operation and maintenance will be provided by our engineer.
2. Some spare parts will be sent with the machine for free. It is available to buy the parts from us forever at low price.
3. We will surpport customers after-service forever by call, email and video etc.
4. If necessary, our engineer is available to go to customer's factory for machine installation and adjustment.
