• Model NO.：YZYX10(95)WK
• Condition：New
• Customized：Customized
• Name：Seed Oil Extractor
• Color：Can Be Customized
• Capacity：150kgs Per Hour
• 24hr Capacity：3.5-4t
• Automatic Type：Semi-Automatic
• Press Tyrpe：Hot Press or Cold Press
• Used for：Sunflower Seed, Peanut, Soybean, Sesame, Rapeseed
• Oil Press Power：7.5 Kw-11 Kw
• Temperature Control Power：2.4 Kw
• Oil Content of Dry Cake：<7.8%
• Transport Package：Wooden Box
• Specification：ISO, BV, SGS
• Trademark：GuangXin
• Origin：China
• HS Code：84792000
• Production Capacity：500 Sets Per Month

Basic Info.

Model NO. YZYX10(95)WK Condition New Customized Customized Name Seed Oil Extractor Color Can Be Customized Capacity 150kgs Per Hour 24hr Capacity 3.5-4t Automatic Type Semi-Automatic Press Tyrpe Hot Press or Cold Press Used for Sunflower Seed, Peanut, Soybean, Sesame, Rapeseed Oil Press Power 7.5 Kw-11 Kw Temperature Control Power 2.4 Kw Oil Content of Dry Cake <7.8% Transport Package Wooden Box Specification ISO, BV, SGS Trademark GuangXin Origin China HS Code 84792000 Production Capacity 500 Sets Per Month

Product Description

Our YZYX10(95)WK Technical Features

Item	YZYX10(95)WK	Remark
Spiral axes rotate speed (r/min )	26-41
Drive form	Triangle belt drive
Temperature control power (kw)	2.4
Power required ( kw )	7.5 or 11	Level 4 Electromotor
Measurement (mm )	1720×580×1185	Length×wide×high
Weight (kg )	590 (with feeding part ) 540 (without feeding part )	No electromotor

1. Series spiral oil press is suitable for the squeezing vegetable oil from rapeseed, cottonseed, soybean, shelled peanut, flaxseed, tung oil seed, investment, high output, strong compatibility and high efficiency. It was widely used in the small oil refinery and rural enterprise



2. Oil press was in the past single plane foundation, after carried on the market demand investigation and study, in short-term research and development new product. It increased the automatic temperature control function, changed the traditional dry cake grinding lifting temperature way, therefore it reduced the working time, and also reduced the waste of power and machine, otherwise it lengthened the life of the machine. If produces interrupted, squeeze chest could keep warm automatically.

Temperature Control Unit


Advantages




Quality Standard
1. Conform to JB/T9793· 1-1999 of the People's Republic of China.
2. ISO9001: 2008 and BV certified.



After-Sale Service
1. We supply spare all year around.
2. We supply technical solutions and helps for buyers at any time.
3. We have professional team, help uses design and plan the oil refinery's construction.

Packing and Delivery
Wooden case with fumigation
