• Model NO.：100-120 tons per day
• Condition：New
• Customized：Customized
• Output(T/H)：100-120tons
• Transport Package：Wooden
• Specification：internatioal standard
• Trademark：pinyang
• Origin：Hubei
• HS Code：8437800000
• Production Capacity：120sets,Year

Basic Info.

Model NO. 100-120 tons per day Condition New Customized Customized Output(T/H) 100-120tons Transport Package Wooden Specification internatioal standard Trademark pinyang Origin Hubei HS Code 8437800000 Production Capacity 120sets/Year

Product Description



 Specification

100-120tons/day complete set rice mill machinery from claner ,destoner ,husker ,whtiner .grader .mist polisher to color sorter ,packing machinery .input capcity will be 5-6 tons per hour ,out put will be 3-4 tons per hour.

Main machine list


Item	Description of goods	quantity
1	TQLZ150                 Vibratory Sieve	1
2	TQSX125A              De-stoner	1
3	MLGT25D*2             Auto Husker	2
4	MGCZ46*20*2        Paddy Separator	1
5	MNMLs40               Whitener	3
6	MJP125*4               White rice plan sifter	1
7	MPG150                 Mist Polisher	1
8	MJP90*7                Wihte rice plan sifter	1
9	512CCD                 color sorter	1
10	DCS50H                Packing machinery	1
11	DTG20/13             Bucket Elevator	5
12	DSTG-6            Low speed gear box Elevator	15

Details Specification

1. TQLZ150 Vibratory sieve is used for primarily for grain cleaning in grain mills and grain storage facilities(silos). It remove coarse and fine impurities from the grain by sieving. It also grades various products according to size.

2. TQSX125A De-stoner primarily used for the food process business enterprise, separate the pebble, mire from wheat, rice etc. That machine adopt double vibration electrical engineering as vibrate source, haveing the characteristics that flap is adjustable and move organization more reasonable, no dust float, hard enduring, easy to dismantle to pack, maintenance, tidy up etc.

3. MLGT25D*2 with double side synchronous belt driving, it is used for husking by relative rotation of  rubber rolls in different speeds. It is characterizd by high output, samll floor space, no oil pollution or noise.

4. mgcz46*20*2 paddy separator with high yielding and strong separation capability; compact structure and smooth operation; sieve made of top quality stainless steel therefore it is robust and smooth, easy and justment and result of separation can be checked at any time; advanced automatic operation, suitable for various kinds of rice and mixtures.

5. MNMLs40 designed in the light of the specific local conditions in China as well as incorporated overseas the most modern techniques of rice milling, it is proven to be perfect rice processing equipment for rice milling plant.

6. MJP125*4  White rice plan sifter is used for white rice grading and choiceness in the rice processing factory. Adopt the serial whole selecting technology. The extraction of whole rice are good; adopt the patent of the sieve aperture that won't be plugged to avoid cleaning the sieve cover; set the knockdown front board to be convenient operation and easy maintenance of the rice bran. The machine is good performance, convenient operation and easy maintenacne.

7. MPG150 Mist polisher has large capacity and high efficiency. The application of combining high wearable polishing cylinder with multirib and subsection structure and subsection sieve with different specifications meets technological requirements of various type of flow control ensures mutilposition high pressure spray, keeping watering uniform and spraying sufficient, there by making polishing effect stable all the time and easy to operate at the same time. With well-designed screen brackets, easy maintenance, easy diassembly, raising work efficiency.

8. 512CCD Color sorter could completely resolve the rejection difficuliies of those different color granules, mildewed granules and faint yellow spot of rice, improve quality and guarantee foods security thereby.

9. DCS50H Packing machine has the advantage of high calculating precision, stable functioning, digital demonstration and easy operation.

Photos
