• Model NO.：NRSDH10
• Materials：Stainless Steel
• Dimension(L*W*H)：1500*900*1500 Mm
• Transport Package：Wooden Case
• Specification：SUS304
• Trademark：Wanyuan
• Origin：Wenzhou China
• Production Capacity：5000

Basic Info.

Model NO. NRSDH10 Materials Stainless Steel Dimension(L*W*H) 1500*900*1500 Mm Transport Package Wooden Case Specification SUS304 Trademark Wanyuan Origin Wenzhou China Production Capacity 5000

Product Description

<span style="font-size: 14px; ">Milk Cream Skimming Machine</span>
<span style="font-size: 14px; ">Disc Separator </span><br /><span style="font-size: 14px; ">2 or 3 phase </span><br /><span style="font-size: 14px; ">ISO</span>
<span style="font-size: 14px; Color: #0000ff; ">Product Description</span>
<span style="font-size: 14px; ">1. Milk Clarifying Separator</span>
<span style="font-size: 14px; ">Milk separator, mainly used to clarify milk. The model can also be used to liquid-solid two-phase separation of similar materials in the industry of juice, beverage and Chinese traditional medicine, etc. </span><br /><span style="font-size: 14px; ">The machine adopts automatic control, and has the advantages such as high efficiency, low material consumption, convenient operation and economic maintenance cost. </span><br /><span style="font-size: 14px; ">The clear liquid is pumped out by centripetal pump, the sludge is discharged automatically and partly. </span><br /><span style="font-size: 14px; ">The machine is one kind of rotary machine with high speed. After accurate dynamic balancing, it can run for long time with low vibraion, safety and security. </span><br /><span style="font-size: 14px; ">2. Milk Cream Separator</span><br /><span style="font-size: 14px; ">Milk separator is mainly used for clarifying and defatting of milk. It is also used for the similar oil to clarify the liquid-liquid-solid three-phase materials. </span><br /><span style="font-size: 14px; ">When the factory get the fresh milk from the farm, there is some impurity and dust or fine animal hair in the milk, firstly it needs the disc separator to clarify and then to the stage of pasteurizer. Some factory needs the skimmed milk to produce butter or cream. After milk clarification, the process needs 3 phase milk separator to degrease, about 3% fat will be discharged from the light liquid phase, skimmed milk comes from the heavy liquid phase, while the impurity outlet from the solid discharge exist. Also, it works for whey and cheese separation. </span><br /><span style="font-size: 14px; ">The skimmed milk and cream are pumped out by centripetal pump, the sludge is discharge automatically and partly. </span>
<span style="font-size: 14px; ">This is picture of our milk separator: </span>

Model	NRSDH5	NRSDH10	NRSDH20	NRSDH30
Output	500L/h	1000L/h	2000L/h	3000L/h
Drum Speed	8000rpm	7320rpm	7320rpm	6500rpm
Motor Power	2.2KW	4KW	5.5KW	7.5KW
Slagging mode	Auto-control	Auto-control	Auto-control	Auto-control
Output Pressure	100-350KPa	100-350KPa	100-350KPa	100-350KPa
Working Condition	Semi-closed	Semi-closed	Semi-closed	Semi-closed
Separation temperature	40-45oC	40-45oC	40-45oC	40-45oC
Fat content	<0.04%	<0.04%	<0.04%	<0.04%
Dimensions	700*550 *800mm	800*600 *1250mm	1000*6200 *1400mm	1100*650 *1250mm
