• Model NO.：Tqlz 125
• Condition：New
• Customized：Customized
• Output：8-13t
• Power(Kw)：0.37*2
• Air Volume(M^3/H)：5000
• Net Weighe(Kg)：800
• Transport Package：Wooden Box Package
• Specification：3100*1500*1700
• Trademark：pinyang
• Origin：Hubei China
• HS Code：8437000000
• Production Capacity：8-13t,H

Basic Info.

Model NO. Tqlz 125 Condition New Customized Customized Output 8-13t Power(Kw) 0.37*2 Air Volume(M^3/H) 5000 Net Weighe(Kg) 800 Transport Package Wooden Box Package Specification 3100*1500*1700 Trademark pinyang Origin Hubei China HS Code 8437000000 Production Capacity 8-13t/H

Product Description

Specifications

The machine is used primarily for grain cleaning in grain mills and grain storage facilities(silos).It remove coarse and fine impuritier from the grain by sieing.It also grades various products cccording to size.
High through capacity and excellent separstion,sturdy design for lesswear,Minimal maintenance requirements
Flexible application possiblilities via optional outlet aspirators,the leaning rffrct would be better.

TQLZ series vibration cleaning sieve( also called screening machine) is applicable to rice, flour, feed, grease, food and chemical factory, set in the cleaning process, the raw material used to remove the large, medium and small and light impurity; and through the equipped with different specifications of the screen hole, the material according to the partical size to classification, get different partical size products.

This machine has high efficiency in removing impurity, stable performance, running balance, low energy consumption, low noise, goof seal performance, install and convenient maintenance.

Feasures
 Compact constrution, low power consumption, well seal low noise.Stable movement, well cleaning effect, higher production efficiency.Driven by vibrating cover can be adjustable according to the requirement.

 Detais



Modle	Output(T/H)	Power(KW)	Air Volume(M^3/H)	Net Weight(KG)	Dimension(L*W*H/mm)
TQLZ100	6-12T	0.37*2	4000	700	3100*1500*1700
TQLZ125	8-13T	0.37*2	5000	800	3100*1750*1700
TQLZ150	10-15T	0.75*2	6000	1100	3100*2250*1700

Photos
