• Model NO.：GD400-S
• Capacity：400-800kg,H
• Steam Needed：0.7-0.8MPa, 250kg,H
• Compressed Air Needed：0.4m³,Min, 0.4-0.6MPa
• Electric Power Needed：10.5kw(Depend on Model)
• Meterial：Stainless Steel
• Transport Package：Wooden Case
• Specification：CE, ISO9001: 2000
• Trademark：tgmachine
• Origin：Shanghai
• HS Code：84382000
• Production Capacity：1set,Month

Basic Info.

Model NO. GD400-S Capacity 400-800kg/H Steam Needed 0.7-0.8MPa, 250kg/H Compressed Air Needed 0.4m³/Min, 0.4-0.6MPa Electric Power Needed 10.5kw(Depend on Model) Meterial Stainless Steel Transport Package Wooden Case Specification CE, ISO9001: 2000 Trademark tgmachine Origin Shanghai HS Code 84382000 Production Capacity 1set/Month

Product Description

INTRODUCTION:
The machine is fabricated based on the similar equipment of NID company from Australia.After being localized,the machine features easy operation and steady working.the processing for the whole line includes cooking,depositing(servo central-filled depositing included),finished product transfering, power disposing and recycling system.
The customer can choose the candy size.Then,we offer our professional layout design for the customer to reach the largest production capacity by approving steady running and stable starch moulds.
This production line is controlled by PLC system with automatic starch molding feeding and unloading. The candy and the powder are separated automaticlly.
Starch adjusting system covers independent drying and cooling template.They are connected by Spiral conveyor driven by motor.


TECHNICAL PARAMETERS:

Model	GD400-S
Production capacity	400-800kg/h According to candy size
Steam needed	0.7-0.8Mpa,250kg/h
Compressed air needed	0.4m³/min,0.4-0.6Mpa
Electric power needed	10.5kw(Depend on model)
Size of starch model	As per customers' request
Occupied Area	About 150m²


Packaging & Shipping

Wooden packing
1. Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing: a. Inside the machine put desiccant b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement

Our Services

After-sale service for abroad customers
1. Free training of machine installion, operation and maintenance will be provided by our engineer.
2. Some spare parts will be sent with the machine for free. It is available to buy the parts from us forever at low price.
3. We will support customers after-service forever by call, email and video etc.
4. If necessary, our engineer is available to go to customer's factory for machine installation and adjustment

Company Information

·Nearly 20 years experiences in food processing machinery production, established in 1982.
·We are manufacturer and wholesale of dough kneading machine
·We adopt environment-friendly materials and technology
·We mainly sell stock in bulk. OEM orders are welcome
· We can accept the mix order
