• Model NO.：QHS-9000
• Capacity：9000L,H
• Processing Types：Carbonated Beverage
• Automatic Grade：Automatic Type with PLC Touch Screen
• Structure：5 Tanks
• Mixing Type：4 Times High Gas Containing
• Material：SUS304
• Drink Mixer Feature 1：Gas Degassing
• Drink Mixer Feature 2：with Heat Exchanger
• Drink Mixer Feature 3：with High Pressure Mixing Pump
• Driven Type：Electric
• Transport Package：Blanket Cloth Package
• Specification：CE, ISO
• Trademark：New Crown Machinery
• Origin：Zhangjiagang City of Jiangsu Province
• HS Code：8438810109
• Production Capacity：20 Sets,Month

Model
QHS-3000
QHS-6000
QHS-9000
QHS-18000
Output
3T
6T
9T
18T
Syrup and water adjusting rate
1:3-1:10
1:3-1:10
1:3-1:10
1:3-1:10
Gas mount (CO2:H2O)
2.5
2.5
4
5
Mixing precision
2%
2%
2%
2%
Cooling water inlet temperature
0-4
0-4
0-4
0-4
Cooling water inlet pressure
0.15-0.25Mpa
0.15-0.25Mpa
0.15-0.25Mpa
0.15-0.25Mpa
Syrup inlet temperature
2~8
2~8
2~8
2~8
Syrup inlet pressure
0.1~0.2Mpa
0.1~0.2Mpa
0.1~0.2Mpa
0.1~0.2Mpa
Inlet pressure of carbon dioxide CO2
0.7~0.8Mpa
0.7~0.8Mpa
0.7~0.8Mpa
0.7~0.8Mpa
Purity of carbon dioxide CO2
99.9%
99.9%
99.9%
99.9%
Working pressure of storage tank
0.45-0.55Mpa
0.45-0.55Mpa
0.45-0.55Mpa
0.45-0.55Mpa
Motor power
5.8kw
6.3kw
14.5kw
7.2kw
External size (L*W*H)
2000×1400×2200
2100×1500×2270
2810×2010×2450
2000×1750×2400
Weight
1200kg
1350kg
1500kg
1950kg


Zhangjiagang New Crown Machinery Co.,Ltd.

Since its establishment in 1997, Zhangjiagang New Crown Machinery has been dedicated to the production and research of beverage machinery. At present, Zhangjiagang City New Crown Machinery can provide filling machines for water, juice, carbonated drinks, beer and other liquids. In addition, Zhangjiagang New Crown Machinery has many patents such as glass bottles and PET bottle filling machines.
 Q: How to get an appropriate offer from New Crown Machinery?
A: Please inform us:
1, production capacity per hour/per day/per month ... ...
2, filling liquid: water, juice, carbonated drink, beer or ... ...
3, bottle type: plastic bottle, glass bottle, can or ... ...
4, cap type: screw cap, crown cap, can lid or ... ...
5, for water treatment, it's better offer us the raw water quality report ... ...

Q: What can I do if I haven't gotten any clue of the production line? I just wanna open a factory and to do the business.
A: Don't worry about this; You can inform us:
1, the exact production you wanna deal with;
2, the budget of the production line; If no budget of the business, I will send you the popular machine in our factory for your ref;
3, we will help tp design everything including the machine layout and factory layout;

Q: This is the first time I cooperate with your factory. How can I trust you about the machine quality?
A: Before ordering the machine, we will make the offer very clear. For example, the material thickness, the brand etc. We can have the video call and I will show what we have in the factory;
Also you can visit us to see the machine;

Q: If the quality doesn't meet my requirement, how can you solve this problem?
A: Before ordering the machine, we will negotiate the machine inspection standard. Then start production; If you are not satisfied with the quality, show us, we will re-do it before shipping;

Q: Can I run the machines in your factory if I buy the complete line in your factory?
A: Sure, why not. We will have the line connected and tested in our factory before shipping even you didn't mention; We will make it working before arriving at your factory;

Q: How can I get the machine?
A: Our company have the export license, so we can help to ship the machine to discharge port that you are available.

Q: How can I install the machine and commissioning? Do you have the technician to my factory?
A: We have the technician available to your factory for machine installation and commissioning; BUT client should be responsible for the round-way flight tickets, technicians' daily salary, local transportation, local hotel and eating.
