• Model NO.：EHDE20111
• Capacity：500-5000 Kg,H
• Pressure：0.5~0.7 MPa
• Transport Package：Wooden Package
• Specification：SUS304
• Trademark：Wanyuan
• Origin：China (Mainland)
• HS Code：8438800000

Basic Info.

Model NO. EHDE20111 Capacity 500-5000 Kg/H Pressure 0.5~0.7 MPa Transport Package Wooden Package Specification SUS304 Trademark Wanyuan Origin China (Mainland) HS Code 8438800000

Product Description

1,Usage:
The machine is used for the concentration of Chinese traditional medicine, wester medicine, starch sugar food and dairy product etc; specially suitable to the low-temperature vacuum concentration of themal sensitive material.

2,Evaporation  Rate (kg/h):
500,1000,1500,2000,2500,3000,5000.

3,Operational Principle:
This system adopts countercurrent operation flow and the whole system adopts negative pressure operation, which has a fast evaporation speed. The first-effect steam is not only used as the second-effect heat source, but also recompressed to be used as the first-effect heat source. That will greatly reduce steam and water consumption during the sourse of the concentration and it can save energy and water.

4, System Composition
low-noise thermal compressor. Fist-effect heater and evaporator, second-effect heater and evaporator,condensator, storage, tank,pilelines

5,Operational Indexes:
while distilling water, use hot press pump with the steam deriving pressure of 0.5~0.7Mpa,
first-effect heating temperature 92~88ºC, first-effect evaporating temperature:75ºC;
second-effect heating temperature:75ºC, second-effect evaporating temperature:55ºC

6, Energy conservation and other features:
1) The steam to water ratio is 0.4, and compared with common double -effect system, it can saves 30% energy and 30% water
2) Low-noise of the thernal compression pump: the pump is firstly developed by our company in domestic. During operation, the pump noise is about 75 dB(A), Which is lower than the noise requirement of pharmaceutical factory
3) The materials which contact with the media parts are SS304.
4) The equipment is used in concentration of water distilling liquid.
5) The machine was firstly manufactured by our company in 2004 which now has produced almost hundred sets, exclusive production by our company.
6) Recommeded by standardization committee of China pharmaceutical equipment industry, national development and reform commission approved, "External heating double-effect concentrator with thermal compressor" Industry standards were formed by our company.
