• Production Capacity：50000PCS,Year
• Model NO.：GX

Model

Capacity (kg/h)

Power (kw)

Size (L*W*H) mm

Weight (kg)

GX-3

3

4

4000×1800×2900

1100

GX-5

5

9

4000×2050×3100

1550

GX-8

8

14.3

4000×2100×3100

1800

4. Working Principle

When gravity separator works, the material falls from the feeding hopper to the work surface. Due to the reciprocating vibration and wind effect of the work surface, the material with a large specific gravity sinks under the material layer, and the light and thin material with a small specific gravity (defective) floating on material surface, forming a preliminary layering grading of finished and defective products. The inferior product in the upper layer is continuously moved along the inclined working surface to  the inferior product area under the action of wind force and gravity, slide into the discharge hopper and exit the machine through the discharge hopper. Because the finished product has a large specific gravity, it is easy to contact the screen surface. It is crawled to the high side by the friction of the screen surface. At the same time, it slides along the screen obliquely into the finished product area, and then exits the machine outside through the hopper. In addition, a part of the mixture is discharged out of the machine as the return material from the return outlet, and then returned to the feeding hopper through elevator to re-screen.

Packing Delivery

First, the brown rice is fed to rice polisher through screw head. the surface of the rice grain is polished by friction under a certain pressure and temperature. Through the polishing treatment, not only the floating surface of the rice grain can be cleared, but also the starch is pregelatinized and gelatinized on the surface of the rice starch, and the starch gelatinization makes up for cracks, thereby obtaining the smooth appearance, improving the storage life of the rice, therefore polished rice is very necessary.

FAQ

1. What is the delivery time of this machine if we book order right now?

We will deliver your order within 30-60days depend on different of machines.

2. How do you pack this machine for exporting?

We will provide packing which is suitable for the agreed means of transportation and for the foreseeable conditions of storage at the destination.

3. How can we make inspection before delivery?

We welcome you send your inspection manager come to our factory for inspection or you can nominate international the third part inspection company.

4. What is the warranty for your machine?

If any defect or non-conformity arising from faulty design, materials, we shall eliminate defects or replace machine.

5. What is the installation requirement of this machine?

The foundation of the machine should be with sufficient strength to support the weight of the machine.

There should be enough space around the machine for maintenance and inspection.
