• Usage：Pharmaceutical, Food Industry
• Clean Type：High Pressure Cleaner
• Washing Model：Ultrasonic
• Transport Package：Exported Wooden Cases
• Specification：CE
• Trademark：Ghamachine
• Origin：Guangzhou, China
• HS Code：842230190
• Production Capacity：20 Sets,Month

Basic Info.

Usage Pharmaceutical, Food Industry Clean Type High Pressure Cleaner Washing Model Ultrasonic Transport Package Exported Wooden Cases Specification CE Trademark Ghamachine Origin Guangzhou, China HS Code 842230190 Production Capacity 20 Sets/Month

Product Description

Introduction
Bottles gets into ultrasonic cleaning trough by bottle-entering inclined hopper, after ultrasonic cleaning, bottle screw carrys them to dial wheel and then into big rotor drum, held by manipulator, fliped 180 ° with bottles down, turning clockwisely with big wheel. under big wheel, the 6 sets of (water/air) jet nozzle with spray needles will insert spray needles into bottles, and then work according to set program: Second recirculated water, one compressed air, one fresh water, & second purified compressed air spray washing. At the same time, water also spray bottle outer, thus finishing the whole washing part. Then manipulators turn bottles with neck up, and get into next part by dial wheel.

Main Parameters

Suitable bottles	Oral liquid bottles, cillin bottles
Working head	40/60 heads
Capacity	160-300BPM
Water consumption	0.6~1m³/h   water pressure: 0.3~.4Mpa
Water consumption	0.6~1m³/h   air pressure: 0.35~0.45Mpa
Power supply	380V 50HZ
Power	13kw
G.W.	1800KG
Dimension	2500×1000×1200mm
