Chinese Traditinoal Medicine Herb Medicine Herb Plant Spray Dryer
Changzhou Jinqiao Spray Drying and Engineering Co., Ltd.- Material：Stainless Steel SUS316, SUS304, Carbon Steel
- Transport Package：Packed in Worden Case
- Specification：ISO9001, ISO14001, CE, HACCP, UL
- Trademark：JQSPRAY
- Origin：Changzhou
Base Info
- HS Code：8419399090
- Model NO.：ZPG
- Production Capacity：50 Sets Per Year
Description
| Specification | ZPG-5 | ZPG-25 | ZPG-50 | ZPG-100 | ZPG-150 | ZPG-1500 | ||
| Air Inlet temperature | 140-220_ , adjustable | |||||||
| Air exhaust temperature | 60-100_ , depend on the product properties and processing requirement | |||||||
| Nominal water evaporationcapacity (Kg / h) | 5 | 25 | 50 | 100 | 150 | 1500 | ||
| E x t r a c t P r o c e s s i n gCapacity (Kg/h) | 5.59-9.5 | 27.9-47.5 | 55.9-95.0 | 111.7-190.0 | 167.6-285.0 | 1676-2850 | ||
| Output (Kg/h) | 0.59-4.5 | 2.9-22.5 | 5.9-45.0 | 11.7-90.0 | 17.6-135.0 | 176-1350 | ||
| Feeding Solid contents (%) | 10-45 | |||||||
| Final moisture contents (%) | 3-5% | |||||||
| Heating method | High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefied petroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify. | |||||||
| Drying tower diameter (mm) | 5300 | 6000 | 6800 | 7500 | 8000 | 8500 | ||
| Overall Dimensions (m) | 14×9×14 | 16×10×15 | 16×12×17 | 18×13×18 | 19×14×19 | 20×15×20 | ||
| Fines collecting method | Two grade cyclone / washing tower | |||||||
| Product collection rate | 95-98%, depend on the product properties and processing requirement | |||||||
