Ghxp-1 Automatic Rotating-Drum Washing Machine
Guangzhou Guanhe Light Industry Machinery Co., Ltd.- Condition：New
- Customized：Customized
- Voltage：220V
- Composition：CIP Cleaning Machine
- Processing Material：Natural Ingredients
- Process：Concentration and Dry
Base Info
- Model NO.：GHXP-1
- Certification：Ce ISO
- Cleaning Process：Ultrasonic Cleaning
- Transport Package：Export Wooden Case
- Trademark：Ghamachine
- Origin：Guangzhou, China
- HS Code：842230190
- Production Capacity：20 Sets, Month
Description
Basic Info.
Model NO. GHXP-1 Certification Ce ISO Cleaning Process Ultrasonic Cleaning Transport Package Export Wooden Case Trademark Ghamachine Origin Guangzhou, China HS Code 842230190 Production Capacity 20 Sets/ MonthProduct Description
GHXP-1 Automatic rotating-drum washing machineIntroduction:
Bottles gets into ultrasonic cleaning trough by bottle-entering inclined hopper, after ultrasonic cleaning, bottle screw carries them to dial wheel and then into big rotor drum, held by manipulator, flipped 180 ° with bottles down, turning clock wisely with big wheel. under big wheel, the 6 sets of (water/air) jet nozzle with spray needles will insert spray needles into bottles, and then work according to set program: Second recirculated water, one compressed air, one fresh water, & second purified compressed air spray washing. At the same time, water also spray bottle outer, thus finishing the whole washing part. Then manipulators turn bottles with neck up, and get into next part by dial wheel.
Technical parameters:
| suitable bottles | oral liquid bottles, cillin bottles |
| working head | 40/60 heads |
| capacity | 160-300BPM |
| water consumption | 0.6~1m³/h |
| water pressure | 0.3~.4Mpa |
| water consumption | 0.6~1m³/h |
| air pressure | 0.35~0.45Mpa |
| power supply | 380V 50HZ |
| power | 13kw |
| G.W. | 1800KG |
| dimension | 2500×1000×1200mm |
Features:
- compact design, reliable performance, convenient operation and economical maintenance.
- with several specification, wide application.
- can be used seperately and also be linked to production line.
- PLC control system, human-machine control panel for bottle-washing, ultrasonic is customized.
- with device to eliminate remnant water.
- adopting screw to achieve bottle entrance or bottle exit, no bottle stuck and broken.
- washing is accordance with GMP requirements.
