• Model NO.：KQ Series
• Application：Milk, Yogurt, Milk Powder, Cheese
• Customized：Customized
• Name：Uht Juice Beverage Water Grape Juice Apple Juice L
• Capacity：500L to 10000L Per Hour
• Control：PLC Control Fully Automatic
• Sterilizing Time：6 to 20s Adjustable
• Temperature：85c to 145c Adjustable
• Material：SS304,SS316
• Sterilizer Contol：Fully Automatic PLC Control
• Sterilizer Heating：by Steam
• Delivery：10 Days
• MOQ：1 Sets
• Packing：Wooden Box
• Motor Brand：Siemens ,ABB ,China Brand
• Spare Parts：Available
• Voltage ,Hz,Phase：Make It to Your Order .
• OEM：Yes
• Transport Package：Standard Woodn Box
• Specification：ISO,SGS
• Trademark：KQ
• Origin：Shanghai, China
• HS Code：8479820090
• Production Capacity：300set Per Year

    mini pasteurizer for milkLG-UHT-1LG-UHT-2LG-UHT-3LG-UHT-4LG-UHT-5Production capacity(L/H)10002000300040005000Inlet temperature5°C5°C5°C5°C5°CHolding time(s)4-154-154-154-154-15Sterilize temperature105~143°C105~143°C105~143°C105~143°C105~143°CProduct outlet temperature2020202020Icewater inlet temperature≤2°C≤2°C≤2°C≤2°C≤2°CSteam pressure0.5MPa0.5MPa0.5MPa0.5 MPa0.5 MPaSteam consumption~150Kg/h~210Kg/h~280Kg/H~350Kg/h~420Kg/hCompressed air pressure0.6MPa0.6MPa0.6MPa0.6MPa0.6MPaCompressed air consumption50L/H50L/H60L/H60L/H70 L/HExternal dimension
(homogenizer excluded)3500×2000×25003500×2000×25004500×2500×22005000×2000×22005000×2000×2200Total weight of machine1700kg2000Kg2200 Kg


UHT Juice Beverage Water Grape Juice Apple Juice Liquid Milk Sterilizer Price .
