• Model NO.：TCQYS
• Transport Package：Wooden Box
• Trademark：COYO
• Origin：China
• HS Code：84371090
• Production Capacity：50000PCS,Year

Model

Capacity (T/H)

Power (Kw)

Size (L*W*H) Mm

TCQYS100

30~60

1.5

3000×1500×2500

TCQYS150

40~80

2.2

3400×1700×2700

TCQYS150-II

60~120

4.0

4400×1800×3100

TCQYS175

80~160

4.0

4700×2200×3500

TCQYS175-II

100~200

5.5

5600×2200×3700

4. Working Principle

This machine can work continuously for cleaning through constant rotation of the round sifting drum by using different particle sizes of raw materials and impurities, to remove large and small impurities from raw materials.

The raw materials enter from the feeding hopper into the sifting drum in a certain included angle with horizontal direction (the inclination angle of sifting drum can be adjusted in a scope of 4°~9° according to different materials and different cleaning requirements), and the inside sifting drum apertures are larger than the normal sizes of finished products, therefore, the finished products and small impurities are all throughs, while large impurities as tailings flow to the outlet of large impurities; the outside sifting drum apertures are smaller than the normal sizes of finished products, small impurities pass through the apertures and flow to the outlet of small impurities, and the tailings are the finished products. At the outlet of finished products, an aspirating opening is prepared and can be fitted with an exhaust system to clean light impurities such as shriveled kernels, bran and dust mixed in finished products; the aspirating opening at the top is used for dust collection.

5. Product Picture

Packing Delivery

First, the brown rice is fed to rice polisher through screw head. the surface of the rice grain is polished by friction under a certain pressure and temperature. Through the polishing treatment, not only the floating surface of the rice grain can be cleared, but also the starch is pregelatinized and gelatinized on the surface of the rice starch, and the starch gelatinization makes up for cracks, thereby obtaining the smooth appearance, improving the storage life of the rice, therefore polished rice is very necessary.

Our Service

[Consulting Service] Our consultant provides you with pre-sales expertise consulting services, system evaluation, providing the best engineering solution

[Engineering Service] Set up special project team of technical, installation and sales for you. to design, install and commissioning a complete set of equipments, whole process tracking service.

[Training Service] Our experts in technology and management provide you long term production, operation, management, maintenance and other professional skills training, to help you train operation, technology, management personnel.

[Spare Part Service] We provides high-quality and reliable original accessories. And the service centers also keep store of a certain number of common accessories to meet the demand of rapid supply.

[Site service] Our service engineer goes deep into your site to solve practical problems. Conduct on-site training on the use of products and seek for improvement of a new way of thinking and method to reduce cost and increase efficiency.

FAQ

1. What is the delivery time of this machine if we book order right now?

We will deliver your order within 30-60days depend on different of machines.

2. How do you pack this machine for exporting?

We will provide packing which is suitable for the agreed means of transportation and for the foreseeable conditions of storage at the destination.

3. How can we make inspection before delivery?

We welcome you send your inspection manager come to our factory for inspection or you can nominate international the third part inspection company.

4. What is the warranty for your machine?

If any defect or non-conformity arising from faulty design, materials, we shall eliminate defects or replace machine.

5. What is the installation requirement of this machine?

The foundation of the machine should be with sufficient strength to support the weight of the machine.

There should be enough space around the machine for maintenance and inspection.
