3000liter Stainless Steel Milk Storage Tank Milk Cooling Tank Milk Cooler

Wenzhou Ranking Imp. & Exp. Co., Ltd.
  • Process：Frozen and Chilled
  • Power Source：Electric
  • Certification：CE
  • Automatic Grade：Manual
  • Application：Milk, Yogurt, Milk Powder, Cheese
  • Customized：Customized

Base Info

  • Model NO.：farm milk cooler
  • Main Material：Ss304
  • Cooling Medium：R404A (Environment Friendly)
  • Storage Temperature：4 Degree Celsius
  • Mixing Speed：25rpm
  • Refrigeration Unit：Copeland , Bitzer , Maneurop
  • Transport Package：Wooden Packaging , Pallet
  • Specification：500L ~ 8000L
  • Origin：China
  • HS Code：8419899090
  • Production Capacity：500PCS, Month

Description

NoModelMCT-5000L1Volume 5000L2Materials used for construction Stainless steel 304 3Shape and orientation Horizontal, Closed Cylindrical4Overall Dimensions 4200 × 2150 × 1800 mm5Weight (kg) 1100kg6Thickness of inner shells mm37Thickness of dimple jacket mm38Thickness of outer shells mm39Thickness of insulation50mm PU10Number of agitator 111RPM of agitator 3012Washing / CIP cleaningWith CIP cleaning ball13Make of compressor Copeland in USA 14Size 12HP15Number of Compressors 116Model of Compressor cooled Air17Number of condensers 218Number of fans 2~419Type of refrigeration R40420Control panel  121power supply380V  50Hz  3phase22PRICFE please contact our on line sales teamFlow rate5T/HLift head24MMotor power1.5PHIn/out let diameter51/38Motor brandABB with CE
Option: Stainless steel 200L 500L Dump Tank Capacity500LMAX capacity550LDimension mmm)L×W×H165×1150×850Inlet pipe Diameter100×1.5Outlet pipe diameterDN40Filter fineness80meshThis dump tank is made of SS304 material
With inner layer mirror polish and out layer mate.
3mm thickness, with a discharge valve at the discharge pipe.

3000liter Stainless Steel Milk Storage Tank Milk Cooling Tank Milk Cooler
5000Liter stainless steel milk storage tank milk cooler
