• Model NO.：200A-3
• Condition：New
• Customized：Non-Customized
• Delivery Time：Within 2 Days
• Color：as Per Requirement
• Capacity：10t,D
• Package：Wooden Case
• Shipment：Msk, Cma
• Size：2850*1850*3270mm
• Weight：5000kg
• Power：18.5kw
• Residual Oil in Cake：7%
• Payment：Tt
• Transport Package：Wooden Cases
• Specification：ISO9001
• Trademark：Sunshine
• Origin：Henan
• HS Code：847920000
• Production Capacity：100 Sets Per Months

Name of oil seeds
Capacity(kg/24hours)
Oil yield(%)
Residual oil in dry cake(%)
Rape seed
9000-12000
33-38
6-7
Peanut
9000-10000
38-45
5-6
Sesame
6500-7500
42-47
7-7.5
Cotton seed
9000-10000
30-33
5-6
Soybean
8000-9000
11-14
5-6
Sunflower seed
7000-8000
22-25
6-7
Rice bran
6000-7000
10-14
6-7
2, Techncial parameters:

    Inside diameter of steaming cooker: Φ1220mm

    Stirring shaft speed: 35rpm

    Steam pressure: 5-6kg/c

    Pressing bores: Front section Φ 180mm

                                Rear section Φ 152mm

    Pressing worm speed: 8rpm

    Feed shaft speed: 69rpm

    Pressing time in cage: 2.5min

    Seed steaming and roasting time: 90min

    Max. temperature for seed steaming and roasting: 125-128ºC

    Power demand: 18.5kw

    Overrall dimensions(L*W*H): 2850*1850*3270mm

    Weight: 5000kg

Package: wooden case or cloth packing

Spareparts of Best price castor oil press machine 200A-3


NameQty.NameQty.1#screw1cake out circle12#screw1copper bearing13#screw1feeding blade14#screw1opposite opening circle15#screw1special screw nut16#screw1fastening screw nut17#screw1pressing plate8ring gasket1slicker8cake adjusting head1Long blade300case1short blades100
Note: It is the best seller in our factory, because it is good quality with much long history experience from users, so if you call for it, we can give you some discount for this type of Soybean oil press soybean oil making machine.
