• Model NO.：TFDS50
• Standard Feed Capacity：500 Kg,One Time
• Tray Quantity：132
• Transport Package：Seaworthy and Land Transportation Packing
• Specification：CE cGmp FDA
• Trademark：Lyomac
• Origin：Shanghai
• HS Code：8419399090
• Production Capacity：1set,2months

Basic Info.

Model NO. TFDS50 Standard Feed Capacity 500 Kg/One Time Tray Quantity 132 Transport Package Seaworthy and Land Transportation Packing Specification CE cGmp FDA Trademark Lyomac Origin Shanghai HS Code 8419399090 Production Capacity 1set/2months

Product Description

Description:

The TFDS serious fruit freeze dryer we prioduced is suitable for frozen  apple, strawberry, mango, pine apple and so on.


Feature:

1, This model is steam heat exchange type. By accessing steam and cold water to increase and decrease its temperature, thus complete the freeze drying process.
2, Freeze drying cylinder is opened in front, so the trolley can go in and out. There are two kinds of cylinder, one is carbon steel Q235-A which is coated imported cabin drinking water paint inside; the other is stainless steel SUS304, the inside of this kind is polished, and the outside uses rubber sponge to preserve heat.
3, Heating plate is made of aluminum which is completely anodic oxidation, the water box adopt plate-fin heat exchanger that ensure plate temperature uniformity and high radiation efficiency.
4, Material tray is food degree aluminum alloy one-time impact briquette; the surface is processed anodic oxidation
5, Material trolley is hanging type, the frame is made of stainless steel SUS304, tray support is made of aluminum alloy, there is position roller on the bottom of trolley, and it can fix the position in freeze drying cylinder.


Operational parts:

1.CIP(cleaning in place) and SIP(Sterilization in place) system.
2.Computer based SCADA system, all data can be recorded by table or curve type, easily print out for preservation.
3.Adjustable shelf space mechanism.
4.Vial stoppering system.



Certificate:



Contact:

Office Add: No.588, Caonong Road, Shanghai-201612, CHINA
Factory Add: B19 Plant, No.500 Kanghe Road, Jiaxing, Zhejiang -314031,CHINA
Mobile: 0086-133-4583-9321
Tel:0086-573-82335102
Fax:0086-573-82335103
Web: lyomac.en.made-in-china.com

For more details about freeze dryer, please feel free to contact us !
