• Model NO.：KLD- Modified starch extruder machine
• Capacity：150kg Per Hour, 250kg Per Hour, 500 Kg Per Hour
• Weight：3t
• Extruder：Single Screw Extuder and Twin Screw Extruder
• Raw Material：Rice, Wheat, Corn and So on
• Transport Package：Wooden Case
• Specification：CE, ISO9001
• Trademark：Jinan Kelid Machinery Co., Ltd
• Origin：Jinan, Shandong
• HS Code：843880000
• Production Capacity：150kg Per Hour, 250kg Per Hour, 500 Kg Per Hour

Basic Info.

Model NO. KLD- Modified starch extruder machine Capacity 150kg Per Hour, 250kg Per Hour, 500 Kg Per Hour Weight 3t Extruder Single Screw Extuder and Twin Screw Extruder Raw Material Rice, Wheat, Corn and So on Transport Package Wooden Case Specification CE, ISO9001 Trademark Jinan Kelid Machinery Co., Ltd Origin Jinan, Shandong HS Code 843880000 Production Capacity 150kg Per Hour, 250kg Per Hour, 500 Kg Per Hour

Product Description

fully automatic industrial Modified starch extruder machine


Introduction of Modified starch extruder machine


1. Description:

Modified Starch is an effective and economical fluid loss agent in water based drilling fluids, which is a starch derivative. It is not bacterial degradation when at 120, environmentally acceptable and non-toxic. Modified Starch can produce a thin, slick, tough filter cake and promotes faster penetration rates with reducer friction. It can be used in all kinds of drilling fluid systems.
Using our machines, you can get oil drilling grade starch suitable for API SPE.13A.Section 10

2. Raw materials:  corn starch, cassava starch, potato starch

3. Products: Oil drilling starch, Pre-gelatinized starch etc.

4. Capacity: 150kg/h,300kg/h

5. Flow chart:Mixing system---Extrusion system---- -Drying system----Milling system---Packing system

6. Voltage in China: Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries

7. Machines Materials:

Machine Material: Stainless Steel #304, thickness:1.2mm
Main Motor: Siemens China brand
Main Electric elements: Siemens or CHNT brand
Inverter: Delta brand


8. Technical Parameters

Model	Installed power	Real power	Output	Dimension
KLD65	81.5kw	53kw	100-150kg/h	21000x1200x2200mm
KLD85	181kw	117kw	300-350kg/h	28000x3500x4300mm


9. Features of Our Twin Screw Extruder:

a. Screw with 38CrMoAL excellent material and being Nitriding treatment Made in Zhoushan, Zhejiang Province China. The HRC hardness is around 60---62.The screws are made by alloy steel and special craft, the screw life is longer. And it has good self-cleaning ability and does not need to discharge or clean the barrel and screw, when roasting or replacing of materials.

b.The extrusion barrel is constructed of carbon steel, is made by #45 steel, stainless steel coating.

c.The gearbox has automatic lubrication function, with extends gear life.

d.Cutting knife fixed in the die head seat, rotary cutting by V-belt drive.

e.We use SIEMENS (CHINA)electrical parts.
f. Main Motor from SIEMENS(CHINA), ensure its Powerful Extrusion and Excellent Performance.


Package & Shipment

Packing:  inside plastic bag, outside wooden case(Based on the customers' need adopt the wooden case or wooden pellets, etc.) for Modified starch extruder machine
Transportation: shipping, train, express or upon clients' demands for Modified starch extruder machine


Services for Modified starch extruder machine

Before sale services for Modified starch extruder machine
1.Provide the free consultation of the equipment
2.Provide the standard device and the flow chart
3. According to the clients'special requirement, offering the reasonable plan and free design helping to select the equipment.

Services during the sales for Modified starch extruder machine
1.Help client design the factory and offering professional advice, free engineering drawing for the factory layout.
2.Welcome to visit our factory or the domestic clients' factory.
3.Inspect the machine before leaving the factory.

After sale services for Modified starch extruder machine
1. Oversea install and debug the equipment.
2. Train the first-line operator.
3. Provide the basic formula
4. Operation/ Service/ Maintenance Manual: Provided In English.
5. We will provide 1-2 engineer to the client's factory for the installation and teach totally in 10 days. The client need provide room, food, round-trip transportation, visa and a nominal $40 daily subsidy per person.


Company Introduction

Jinan Kelid Machinery Co; Ltd. is a professional supplier of food processing machines. Our company's Motto is: "Technology Makes Easy". We offer to cooperate with our customers for mutual and beneficial development. All Inquiries are welcome.
We are located in Jinan, the Capital of Shandong Province. Jinan Kelid Machinery Co; Ltd is vested with many staffs with many years of experience in supplying the food processing machines.
Our main products line include food extrusion machine, soya meal/meat processing machines, industrial micro wave oven, packaging machines, rice cake machine etc... Most importantly, we also provide formulas, technology supports, machine inspection service, etc^..
Cooperating with different manufacturers and research centers, we provide the food processing machines with outstanding quality. We have a group of experienced experts and outstanding engineers who do provide the professional service delivery and installation. Based on the clients specific requirement, we also design and produce the machines to order. We have through the years established good working relationship with some reputable organizations both at home and abroad with outstanding goodwill.
Whatever food processing machine you need from China, contact: Jinan Kelid Machinery Co; Ltd. A one stop shop in the middle of China.

FAQ about Modified starch extruder machine

1. What's the materils?
 Answer: Stainless steel

2. How long is your gurantee time?
 Answer: One year after comissioning.

3.How is the installation?
Answer: When the machine arrives at the your workshop, we send 1-2 engineers to install the machine and teach the workers how to use.
There be a operate mannual and Equipment maintenance manual.

4.I want to do more tastes. It is ok?
Answer:  We will supply a basic formula.
You can adjust and find the best formula to meet your target market's taste.

5.How is the payment?
Answer: 40% TT as downpayment, 60% TT or L/C before shippment.
Before shippment,welcome to inspect the machine.
