• Quality Standard：European Standard
• Control System：PLC Control System
• Cleaning：Corn Cleaning Machines
• Dampering：Double Floor Damper
• Degerminating：Degermintor
• Milling：Corn Roller Mill
• Packing Section：1kg.2kg. 10kg and 50kg
• Steel Pipes：Steel Stainless Pipes
• Roller Mill：Automatic Roller Mill
• Transport Package：Container, Suitable for Sea Transportation
• Specification：standard
• Trademark：SJZ Africa
• Origin：Hebei, China
• HS Code：870000
• Production Capacity：30sets, Year

Basic Info.

Quality Standard European Standard Control System PLC Control System Cleaning Corn Cleaning Machines Dampering Double Floor Damper Degerminating Degermintor Milling Corn Roller Mill Packing Section 1kg.2kg. 10kg and 50kg Steel Pipes Steel Stainless Pipes Roller Mill Automatic Roller Mill Transport Package Container, Suitable for Sea Transportation Specification standard Trademark SJZ Africa Origin Hebei, China HS Code 870000 Production Capacity 30sets/ Year

Product Description

Corn Mill, Maize Flour Mill, Corn Milling Machine
1. factory manufacturer for supplying 10t/day to 500t/day.
2. most welcome come and see all running corn mill in our factory.
Technical data:
WORSHOP REQUEST: (L*W*H) 37M*11.5M*22.5M FIVE FLOOR BUILDING;
CONSTRUCTION REQUEST: 400KG/
(NOT INCLUDE THE FINISHED PRODUCT BIN)
TOTAL POWER IS AROUND 1100KW(DEPENDING ON EXACTLY DESIGN).

The Main Machine is: Maize cleaner; Moinsture damper, degerminator, aspirator, roller mill, plansifter, auto packing machine.
The Feature of each machine.
1. Roller Mills
1)The partitioned paneling and swing-out feed module guarantee ideal access to the feeding and grinding rolls. This makes residue-free cleaning possible;
2) a pulse generator automatically adjust the feed material at the entrance doo;
3) bearing SKF;
4) temperature monitor (option).
2. Roller: Two different alloys with a mixing ratio allow the perfect balance to be achieved between hardness and roughness.
3. Plansifter
1) Material: High-strength alloy steel;
2)up and down sifter circles with steel plate overall by bending;
3)Transmission system using spring force component institutions;
4)Sieve frames of wood coated with synthetic resin, without backwire;
5)All the inside walls as well as the doors are provided with high-grade insulation;
6)Vertical and horizontal clamping system.
4. Degerminator: Dry degermination with low fat content. Combined with Europe, Asia and Africa Technology. Multi-faceted sieve tube design, the screen. The high-quality stainless steel nitriding treatment.
5. Gravity grading sifter: Combined globoidal and Plane sifting form, different weight nature classification
6. Dampener: Stainless steel. Bi-directional screw, Prevent free water, an intensive Intermixing(maize).
7. Bucket elevator and conveyor with reducer, High-quality carbon steel painting, stainless steel(option).
8. PIPE: Stainless steel.
9. Moisture bin and store bin: Stainless steel (for maize ).
10. Plant Control System:
Option 1: Mimic board, auto-control; CCTV surveillance system;
Option 2: PLC control system with CCTV surveillance system realize Seamless integration.
11. Electronic parts: Siemens/Delixi.

project  which we have done	country
150T/24h corn flour mill	zambia
500T/24h corn flour mill	South Africa

Corn Mill/corn flour mill/corn milling machine/corn machine/corn flour milling machine/corn roller mill/corn grinder/corn flour factory/corn flour plant/corn
