Pressure Sprey Dryer Ypg Series Pressure Granulation Sprey Dryer High Dryer
Changzhou Jinqiao Spray Drying and Engineering Co., Ltd.- Processing Material：Special Agricultural Products, Natural Ingredients
- Application：Pet Food, Chocolate, Ice Cream, Vegetable, Fruit, Dairy, Beverage
- Certification：CE, UL, ISO9001
- Power Source：Gas
- Automatic Grade：Automatic
- Material：Stainless Steel SUS316, SUS304, Carbon Steel
Base Info
- Transport Package：Packed in Worden Case
- Specification：ISO9001, ISO14001, CE, HACCP, UL
- Trademark：JQSPRAY
- Origin：Changzhou
- HS Code：8419399090
- Production Capacity：8 Lines Per Year
Description
Specifications
YPG-25
YPG-50
YPG-100
YPG-150
YPG-200
YPG-300
Air Inlet temperature
140-550 ° C (depend on the product to be dried, and URS)
Air exhaust temperature
60-120 ° C (depend on the product to be dried, and URS)
Nominal water evaporationcapacity (Kg / h)
25
50
100
150
200
300
Heating method
High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefiedpetroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.
Drying tower diameter (mm)
1200
1400
1600
2200
2600
3200
Overall Dimensions (m)
5×4×12
6×4×13
6×4×15
8×4.5×19
10×5×20
12×6×22
Product yield
95-99.9%_depend on the properties of the product and configurations
Specifications
YPG-500
YPG-1000
YPG-2000
YPG-5000
YPG-10000
YPG-15000
Air Inlet temperature
140-550 ° C (depend on the product to be dried, and URS)
Air exhaust temperature
60-120 ° C (depend on the product to be dried, and URS)
Nominal water evaporationcapacity (Kg / h)
500
1000
2000
5000
10000
15000
Heating method
High-pressure steam, or steam + electricity, or any kinds of fuel (diesel, natural gas, liquefiedpetroleum gas or coal, etc.), or solid fuel (any combustible material). Please specify.
Drying tower diameter (mm)
3800
5500
7300
10000
14500
17500
Overall Dimensions (m)
Design as per configuration of the plant and URS
Product yield
95-99.9%_depend on the properties of the product and configurations
Note:These parameters for reference only and will be changed as per URS.
