• Model NO.：DTC
• Voltage：380V,220V
• Rotating Speed：25-55r,Min
• Transport Package：Wooden Case
• Specification：CE, ISO9001: 2008
• Trademark：tgmachine
• Origin：Shanghai

Basic Info.

Model NO. DTC Voltage 380V/220V Rotating Speed 25-55r/Min Transport Package Wooden Case Specification CE, ISO9001: 2008 Trademark tgmachine Origin Shanghai

Product Description

Features:

1.New design with perfect fashion,more reasonable structure,more advanced tecnology.

2.Inpoted PLC control system and,colorful touch screem,easy operation,intuitionist and efficient.

3.Inported servo film drawing system and color sensors,acurate positing,and superexcellent capability for complete machine,perfect packging.

4.With auto warming protection function to minimized loss.

5.High precision,high efficiency.

6.The machine completes the whole procedure of feeding,measuing,bag making,date priting,air charging(exhausting),outputting.

7.Suiutable for various kinds of bag,it could provide the pillow bag,angle fold bag,hang hole bag,link bang,ect

Standard Features:

1. The machine can automatically complete the products measuring, conveying and feeding, filling and bag forming, date code printing, bag sealing and cutting.

2. Servo-motor driven, twin belt bag pulling system.

3. High sensitive fiber optic photo sensor can automatically trace color mark accurately.

4. PLC control system combined with touch screen, can easily set can change the packing parameters. Daily production output and self-diagnostic machine error can be viewed directly from the screen.

5. PID temperature controller monitors heat sealing temperature within ±1°C.

6. Automatic edge position control assures consistent film alignment during production to produce uniform bag quality.

7. Selected electrical and pneumatic components from reliable international manufacturer.

Application:
Automatic packaging of liquid, powder and granule in formed pouch for the food, pharmaceutical, chemical and other industries.
It is suitable for the high accuracy and easy fragile material,such as puffy good,crispy rice jelly candy,pistachio,dumping,chocolate,medicine,pet food,small hardware ect.

OPTION:two synchounous belt device,angle fold device,automantic rectifying device,holepunching device,link bag device

Technical Parameters:

Condition	New
Place of Origin	China (Mainland)
Brand Name	SHINWEI
Model Number	DTC-420        DTC-520
Application	Candy
Voltage	220V
Power(W)	2.2kw
Weight	650kg            680KG
Dimension(L*W*H)	L1217*W1015*H1343mm  L1510*W1260*H1600mm
Certification	CE
Warranty	1
After-sales Service Provided	Engineers available to service machinery overseas
Max.film width	Max.420mm    Max.520mm
Bag length	80*300mm     80*350mm
Bag width	60*200mm      50*250mm
Packaging speed	5~60bag/min     5~60bag/min
Measuring range	150-1500ml      150-2000ml
Flim thickness	0.04-0.08mm
Power	220V 50/60Hz 2.2Kw
Packing material	BOPP/CPP,BOPP/PE,PELT/AL/PE,NY/PE,PAPER

Type	DTC-680
Film width	420mm
Bag length	80 to 300mm
Bag width	60 to 200mm
Film roll diameter	320mm
Range of measurement	150 to 1500ml
Film thickness	0.04 to 0.08mm

Type	DTC-800
Film width	520mm
Bag length	80 to480mm
Bag width	80 to 250mm
Packing rate	10 to 50 bags/min
Film roll diameter	320mm
Range of measurement	150 to 2000ml
Film thickness	0.04 to 0.09mm

Type	DTC-900
Film width	900mm (maximum)
Bag length	100 to 480mm
Bag width	100 to 350mm
Packing rate	10 to 45 bags/min
Film roll diameter	400mm (maximum)
Range of measurement	150 to 5000ml
Film thickness	0.046to 0.12mm
