Machinery FOR Food Beverage Cereal

Home > Product > Snack Machinery

Chocolate Coating Pan Nut Coating Machine

Shanghai Target Industry Co., Ltd.
  • Certification：CE, ISO9001
  • Power Source：Electric
  • Process：Thermal Processing
  • Automatic Grade：Automatic
  • Application：Candy, Chocolate
  • Customized：Customized

Base Info

  • Model NO.：PG
  • Capacity：as Per Model
  • Material：SUS
  • Transport Package：Wooden Case
  • Specification：CE; ISO9001
  • Trademark：TG Machine
  • Origin：China Shanghai
  • HS Code：84382000
  • Production Capacity：as Per Model Coating Machine

Description

Basic Info.

Model NO. PG Capacity as Per Model Material SUS Transport Package Wooden Case Specification CE; ISO9001 Trademark TG Machine Origin China Shanghai HS Code 84382000 Production Capacity as Per Model Coating Machine

Product Description


These machines sugarcoat the tablets and pills for pharmaceutical and food industries. It is also used for rolling and heating beans and edible nuts or seeds
Main Features:
1. Sugarcoating round pot is elevated 30 degree to horizontal.
2. Temperature of electrical heater can be adjusted.
3. Pipe of the blower stretches into pot for heating or cooling purpose.
4. Thermal capacity can be selected in three levels (1000Kw,2000Kw,3000Kw).

Diameter
600mm
800mm
1000mm
1250mm

capacity
8-15/Kg/time
30-50/Kgtime
50-70/Kgtime
90-150/Kgtime

the speed of pan
40r/min
32r/min
32r/min
30r/min

angle
15°-45°
15°-45°
15°-45°
15°-45°

motor power
0.75Kw
1.1Kw
1.5Kw
2.2Kw

fan power
100w
200w
200w
370w

in -out power
1000w+1000w
1500w+2000w
2000w+2000w
4000w+2000w

size
780×600×1360
1150×800×1550
1150×1000×1600
1340×1250×1680

weight
115kg
240Kg
250Kg
400Kg

Chocolate Coating Pan Nut Coating Machine

Services
COATING MACHINE
After-sale services for all the customers    a. Free training of  machine installation, operation and maintenance will be provided;b. Some spare parts will be sent together with the machine for free and some spare parts are  always at favorable price for regular customers;    c.Technical support will be offered by call, email or video etc;   d.If necessary, our engineer will go to your factory for machine installation, adjustment or maintenance.

Shipment
COATING MACHINE
Wooden packing
1.Product production is completed, by the quality inspection department to check
2.After inspection qualified, clean for whole machine
3.Packing: a. Inside the machine put desiccant b. Add 6 cm thick foam plate  around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4.Container:according to different products for reinforcement
