• Model NO.：Q110,111,112,113
• Capacity：0.5-2.5ton,Class
• Weight：1000-6200kg
• Power：9-28kw
• Voltage：380V,220V
• Transport Package：Wooden Case
• Specification：CE, ISO9001: 2008
• Trademark：tgmachine
• Origin：Shanghai

Basic Info.

Model NO. Q110/111/112/113 Capacity 0.5-2.5ton/Class Weight 1000-6200kg Power 9-28kw Voltage 380V/220V Transport Package Wooden Case Specification CE, ISO9001: 2008 Trademark tgmachine Origin Shanghai

Product Description

Application:
The moulding line is for chocolate deposit forming. The whole process is fully automatic including depositing,mould plate vibrating,cooling,demoulding,conveying and plate heating.You can choose one head,two heads or three heads moulding line for different products.The line is suitable for pure chocolate,center filled chocolate,two color chocolate,four color chocolate,amber or agate chocolate,etc.

Technical Parameters:

Model Project	Q110	Q111	Q112	Q113
Capacity ton/class	0.5~1.5	0.8~2.5	0.8~2.5	0.8~2.5
Total power lncluding freezer	9	21	23	28
Refrigeration quantity kcal/hour	Don't have	21800	21800	21800
Mould plate size mm	275×175×30	280×200×30	280×200×30	280×200×30
Mould plate quantity (m)	270	270	380	420
Weight (kg)	1000	4800	5800	6200
Outside dimensions mm	3600×725×1560	17010×1010×1330	17060×1005×1870	18600×1200×2400

Shanghai Target Industry Co., Ltd is the sales and service company for Shanghai SHINWEI Machinery Manufacturing Co., Ltd which is the first manufacturer to build the complete production line for depositing hard candies in China and has accumulated 40 years' fabrication experience. It is also one of the leading and professional exporters in China by providing customers home and abroad with high quality confectionery, chocolate, biscuit and packaging machinery. Our machineries have been exported to East European, south America, middle east, southeast Asia.

As the first-class corporation for fabrication of confectionery, chocolate, biscuit and packaging machinery, Target Industry offers not only the advanced equipment with competitive and economical efficiency, but the whole solutions for the customer's demands also. We provide the design, production, assembly and commissioning work of small or medium confectionery and biscuit machines in accordance with the customer's specific requirements.
