• Model NO.：JMJ500
• Transport Package：Wooden Case
• Specification：CE
• Trademark：SHINWEI
• Origin：Shanghai China
• Production Capacity：20sets,Year

Basic Info.

Model NO. JMJ500 Transport Package Wooden Case Specification CE Trademark SHINWEI Origin Shanghai China Production Capacity 20sets/Year

Product Description

Chocolate maker, the part of chocolate processing machine, made and produced according to eccentric sliding-vane principles, adopt jacketed structure to keep temperature by hot water, protect all day work for syrup transportation and heating. It's the ideal conveying pump for chocolate syrup transporting for the foodstuff line and medicine, fat oil, chemical industry and other fields as well.


It consists of three parts: Pump body, speed-down and motor. It has reasonable and compact structure with steady, dependable working and low proportion of maintenance for malfunction. In order to convenient for installation, the pump input can be adjusted feed-in position optionally as per the special requirement based on working area.
The pump adopt high strong casting technology of higher hardness, long life. As the requests from different purpose, The pump can be made from various materials, such as rot-proof, anticorrosion and it can be cleaned and maintained on the working spot without removing connection pipes.
The pump equipped with step-less speed regulator for controlling and adjusting material outputs freely so that it can make the paralleling purpose for the previous syrup preparation to meet the later production demand. It really affects the wide range and huge quantity of production

model	JMJ20/40	JMJ100	JMJ500	JMJ1000	JMJ3000
Maximum capacity(L)	20/40	100	500	1000	3000
Grinding Fineness (micron)	20-25	20~25	20~25	20~25	20~25
Main axle rotating speed (rpm)	93	48	33	28	35
Grinding time (h)	8-10	12~16	16~22	16~22	16~22
Main motor power(kw)	1.5	5.5	15	22	45
Electrical heating power (kw)	0.6	2.5	5	6	12
Weight(kg)	500	1050	2572	4850	7500
Dimensions(mm)	1000×800×800	1200×1150×1050	2000×1860×1280	2918×1650×1920	3450×2016×2280

Wooden packing
1. Product production is completed, by the quality inspection department to check
2. After inspection qualified, clean for whole machine
3. Packing: A. Inside the machine put desiccant b. Add 6 cm thick foam plate around the machine, Then, winding stretch film for reinforcement, and combined with bubble wrap c. On wood packaging on the outside of the machine, then use metal reinforcement with steel
4. Container: According to different products for reinforcement



After-sale service for abroad customers.

1. Free training of macine installion, operation and maintenance will be provided by our engineer.
2. Some spare parts will be sent with the machine for free. It is available to buy the parts from us forever at low price.
3. We will surpport customers after-service forever by call, email and video etc.
4. If necessary, our engineer is available to go to customer's factory for machine installion and adjustment





Why choose us?

· Nearly 20 years experiences in food processing machinery production, established in 1982.

· We are manufacturer and wholesale of dough kneading machine

· We adopt environment-friendly materials and technology

· We mainly sell stock in bulk. OEM orders are welcome

· We can accept the mix order
