• Model NO.：ZT
• Model：100L
• Power：0.75kw
• Material：Stainless Steel
• Heating Method：Electric Heating
• Thickness：4mm
• MOQ：1set
• Polish：300 Mesh
• Jacket：Double
• Quality：Excellent
• Control：Button Control Panel
• Transport Package：Ply Wood Case
• Specification：Stainless steel
• Trademark：ZHITONG
• Origin：Guangzhou
• HS Code：8479820090
• Production Capacity：5000

Basic Info.

Model NO. ZT Model 100L Power 0.75kw Material Stainless Steel Heating Method Electric Heating Thickness 4mm MOQ 1set Polish 300 Mesh Jacket Double Quality Excellent Control Button Control Panel Transport Package Ply Wood Case Specification Stainless steel Trademark ZHITONG Origin Guangzhou HS Code 8479820090 Production Capacity 5000

Product Description

Pneumatic lifting high speed disperser















The material is stirred through the center of the upper part of the emulsifying pan, and the PTFE scraper plate always caters to the shape of the mixing pot, sweeps away the wall-sticking material, and causes the scraped material to produce a new interface continuously, and then cuts off, compresses and folds the blade and the rotating blade. Make it agitate, mix and flow down to the homogenizer below the pot, and the material is cut through the process of strong cutting, impact and turbulence between the high-speed rotating cutting wheel and the fixed cutting sleeve, and the material is cut in the shear seam. The particles of 200nm-2um were broken rapidly. Because of the vacuum in the emulsifying tank, the bubbles produced in the stirring process of the material were extracted in time. By means of vacuum extraction, the products produced are no longer mixed with bubbles in the stirring process, thus ensuring the production of high-quality products full of luster, fineness and good extensibility.

Item	High Shearing Dispersing Homogenizing Emulsifier
Model	ZT-15KW
Motor	ABB Motor
Power	15KW
Speed(RPM)	2920
Flow (M3/H)	<16 M3/H
Size of Pipe outlet	50mm
Voltage	380V 50HZ 3 Phase
Material	All parts are stainless steel except the motor, contact parts is SUS316L
Import and Export Caliber	Import :DN65 , Export: DN50
Direction of Inlet and Outlet	Sucking in from Vertical, expelling from the radial direction
Protective Level	IP55
Mechanical seals	Double mechanical seal, need to cooling water cooling mechanical seal
Static seal	Fluorous rubber, PTFE
Max allowable Temp.	100 degree Celsius
Finish	Part of contacting material Ra0.4 and other parts Ra0.8
Structure of rotor and stator	Rotor and stator occlude,material is SUS316L,3 group in all
Structure	Horizontally installing on the outside of vessel, contacting with pump and can process circularly
