2021 Best Flour Processing Line 50ton Maize Flour Milling Machine

Shijiazhuang Hongdefa Machinery Co., Ltd.
  • After-sales Service：Aftersales Department
  • Warranty：Five Years
  • Type：Flour Mill
  • Application：Flour, Wheat, Maize Corn
  • Voltage：380V, 50Hz
  • Appearance：Vertical

Base Info

  • Model NO.：HDF maize flour milling machine
  • Press Materials：Corn Maize
  • Press Series：Second
  • Condition：New
  • Customized：Customized
  • Material：Steel Structure Maize Milling Machine
  • Capacity：5-500t,24h
  • Brand Name：HDF Flour Mill
  • Flour Extraction：75%-85%
  • Mill Product：Corn Maize Flour, Super Maize Meal, Feed
  • Manufacture：Shijiazhuang Hongdefa Machinery Co., Ltd
  • Export Department：Shijiazhuang Africa Trading Company
  • Service：Shipping, Plant Construction, Installation
  • Pipes：Stainless Steel in Milling Section
  • Branch Offices：Zambia Uganda Ethiopia for Overseas Service
  • Maize Roller Mill：Pneumatic Roller Mill
  • Maize Sifter：Double Section Sifter
  • Maize Damper：Moisture Damper
  • Maize Degerminator：Japan Technology
  • Warranty Time：Two Years
  • Transport Package：Crates Plastic Film
  • Specification：5-500T
  • Trademark：HDF maize flour processing line
  • Origin：Hebei China
  • HS Code：843780000
  • Production Capacity：5t-500t,24h

Description

FINENESS BY MASSMINMAXMINMAX1.  Samp-1.5-0.8Not more than 5% shall be whole grain and not more than 5% shall pass through a 2.36mm sieve.2. Maize Rice-1.5-0.8At least 90% shall pass through a 4.0mm and not more than 5% shall pass through a 1.18mm sieve.3. Maize Grit-1.5-0.8At least 90% shall pass through a 1.4mm sieve and less than 90% shall pass through a 300 micrometer sieve.4. Maize Flour-Less than 2.0-0.8At least 90% shall pass through a 300 micrometer sieve.5. Super Maize Meal-Less than 2.0-0.8At least 90% shall pass through a 1.4mm sieve and less than 90% shall pass through a 300 micrometer sieve.6. Special Maize Meal2.0Less than 4.0-1.2At least 90% shall pass through a 1.14mm sieve.7. Sifted Maize Meal3.0Less than 4.0-1.2At least 90% shall pass through a 1.14mm sieve.8. Unsifted Maize Meal3.5Less than 4.5More than 1.22.5At least 90% shall pass through a 1.14mm sieve.9. No.1 Straight Run Maize Meal3.7-1.82.5At least 90% shall pass through a 2.36mm sieve.10.No.2 Straight Run Maize Meal3.7-More than 2.56.5At least 90% shall pass through a 2.36 mm sieve.11. Unsifted Crushed Maize3.2112.5Not more than 5% shall be whole grain,and not more than 40% shall pass through a 2.36mm sieve12. Sifted Crushed Maize1.5--2.0Not more than 5% shall be whole grain,and not more than 5% shall pass through a 1.18mm sieve13. Fine Crushed Maize1.5--2.0At least 90% shall pass through a 2.36mm sieve and not more than 10% shall pass through a 1.0 micrometer sieve.14. Maize Germ Meal10.0----15.Fine Maize Bran-Less than 10.0More than 6.517.0At least 90% shall pass through a 2.0mm sieve and at least 50% shall pass through a 1.4 micrometer sieve.16. Coarse Maize Bran-Less than 10.0More than 6.517.0-17. Industrial Grade Maize Product-----Though not strictly applicabe to products many of the above fat and fibre contents are still recommend in most company based quality matrix.
2021 Best Flour Processing Line 50ton Maize Flour Milling Machine

QUOTATION DETAILS FOR 50T/24H MAIZE FLOUR PROCESSING LINE

A: PAYMENT ITEMS:
30% BY T/T AS DEPOSITE;
70% Before shipping by T/T

 B:DELIVERY TIME:2MONTHS

 C.RESPONSIBILITY

  1:SELLER:  1)MACHINE DELIVERY SHOULD BE ON SCHEDULE
              2)1CHINESE ENGINEER GUIDE INSTALLATION,1CHINESE MILLER .
                 THE CHINESE ENGINEER SHOULD FOLLOW THE LAW OF THE
                 WORKING PLACE
              3)GUARANTEE THE MACHINE QUALITY FOR 1YEAR

   2.BUYER:  1)SUPPLY THE WATER ,ELECTRICITY INSIDE OF THE WORKSHOP
                        2)SUPPLY THE FORK LIFTER,AND VERTICAL LOADING TOOLS
                        3)4-8 LOCAL WORKERS TO ASSIST INSTALLATION,THE CHARGES (INCLUDE SALARY, FOOD ETC) SHOULD BE PAID BY THE BUYER
                        4)SUPPLY THE LIVING PLACE AND FOOD FOR THE CHINESE ENGINEER,
                 AND SALARY 1500USD/MONTH/ENGINER
2021 Best Flour Processing Line 50ton Maize Flour Milling Machine

If you are interested in this set of Best Flour Processing Line 50ton Per Day Maize Flour Milling Machine, welcome to contact us freely!
Thank you!
Wiwi Zhang

2021 Best Flour Processing Line 50ton Maize Flour Milling Machine2021 Best Flour Processing Line 50ton Maize Flour Milling Machine2021 Best Flour Processing Line 50ton Maize Flour Milling MachineOther maize milling projects
