• Model NO.：XGF
• Dosing Device：Surface Type
• Filling Type：Hot Filling
• Power Type：3.75kw
• HS Code：8422301090, 8422301090
• Filling Principle：Pressure
• Capacity：4000-12000bph
• Bottle Size：0.2L-10L
• Transport Package：Wooden Case
• Specification：sus304
• Trademark：keyuan
• Origin：China Jiangsu

Basic Info.

Model NO. XGF Dosing Device Surface Type Filling Type Hot Filling Power Type 3.75kw HS Code 8422301090, 8422301090 Filling Principle Pressure Capacity 4000-12000bph Bottle Size 0.2L-10L Transport Package Wooden Case Specification sus304 Trademark keyuan Origin China Jiangsu

Product Description

Automatic  3 in 1 juice hot filling machine made in China

Automatic  3 in 1 juice hot filling machine made in China --images

 Rinser
-Rotative rinsing turret one treatment, fixed nozzles, with grippers.
-The grippers take the bottles from the inlet star-wheel while they are still driven by the star-wheel, thus guaranteeing a safe grip.  -After the gripping, the bottle is turned upside down and cantred above a spraying nozzle which directs a stream of rinse water into the bottle. After the draining period the bottle is turned over to an upright position again. Filler
-The star-wheels drive the bottles always "by the neck" through the rinsing, filling and capping steps. For the various types of bottle, it is easy to adjust the structure for the operator by our specialized design.
-Product bowl is to reduce the loss of heat.

-If the temperature is low than the setting value, the filling valves will stop and return the last beverage in filling valve to recycle tank and return to UHT again to sterilize with pump.Capper
-Rotative capping turret, suitable to the application of screw plastic caps on PET bottles
-The fixed part consists of the cap hopper, the cap feeder with relevant motor and the cam actuating the capping heads.

-The heads are raised and lowered by the action of a follower that is riding on a shaped cam.


 Automatic  3 in 1 juice hot filling machine made in China --Technical Dates

Model	XGF8-8-3	XGF12-12-6	XGF18-18-6	XGF24-24-8	XGF32-32-10	XGF40-40-10
Rinsing Head No	8	12	18	24	32	40
Filling Head No	8	12	18	24	32	40
Capping Head No	3	6	6	8	10	12/10
Rated Capacity (500ml)	2000BPH	4000BPH	7000-8000BPH	10000-12000BPH	12000-15000BPH	15000-18000BPH
Overall Size (mm)	1900*1420*2000	2200*1600*2300	2450*1900*2300	2750*2180*2400	4000*2300*2300	4550*2650*2300
Weight	1.5T	2.2T	3.0T	4.0T	8.0T	12.0T
Power(KW)	2.0kw	3.5kw	4.0kw	4.8kw	7.6kw	8.3Kw



Automatic  3 in 1 juice hot filling machine made in China --company   introduction


 why   choose    us   ?
We're the professional manufacture for various kinds of beverage equipment.
As mineral water pure water filling machine
pure water filling line .juice making machine .
carbonated drink cola , glass bottle beer filler machine,
Alumium cola/beer can, and etc.
All our products with Certificate: CE approved.SGS approved
2. Application field :
(1). The three functions of bottle washing, filing and capping are composed
in one body of the machine . (2). The whole process is automatic . (3). So this machine has three steps ,the  first is washing, the second is filling,
the third is sealing the bottle .
3. Features:(1) Low power consumption, better material SUS 304, SUS 316. (2) Small size,simple structure,low investment (3) Auto complete line, need less worker .
4. Project design:

We can design any project of the completer line to meet the demands of our clients, considering both factory
Certification


 Juicing and Juicer Filling Machine /Bottling Machine--packing&shipping

Packaging Details:   Wooden Packing For Fruit Juice Making Machine
Delivery Detail:     Shipped in 30 days after payment Juicing and Juicer Filling Machine /Bottling Machine--services
Pre- sales Phase:
1.We have sales representative to communicate with our client to understand client needs and based on our experience,        capacity to initiate the draft proposal for our client review.
2With the proposal review, analysis and improvement, we will finalize our proposal with our clients.
Production Phase:
1.We have very strong filing machine business experience and downstream/upstream partnership.
2.Under the criteria of customized quality, our good production scheduling will make sure our client filling machine will be    delivered in time.
After-sales Phase
1.2  years  warranty for the whole system
2.equipment installation and debugging
3.we can provide internship service and help you train the operator and mechanic
4.we can help you to design the product line,workshop and provide turn-key project.
 5.24 hours technical support by email
