• Model NO.：QGF
• Filling Valve Head：Multi-Head
• Material Type：Liquid
• Filling Principle：Pressure
• Structure：Rotary,Linear
• Feed Cylinder Structure：Single-Room Feeding
• Filling Capacity：18.9L
• Weight：3500kg
• Power：3.3kw
• Voltage：380V
• Material：SS304
• Transport Package：Wooden Case
• Specification：3550*1200*1800mm
• Trademark：Sunswell
• Origin：Zhangjiagang Jiangsu China
• HS Code：8422400000
• Production Capacity：60 Sets,Year

Main technical data
Model
QGF-100
QGF-300
QGF-450
QGF-600
QGF-900
QGF-1200
QGF-2000
Number of filling heads
1
2
3
4
8
12
16
Filling capacity
18.9
18.9
18.9
18.9
18.9
18.9
18.9
Barrel size (mm)
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
φ270×490
Production capacity (b/n)
100-120
200-240
300-400
600
900
1200
2000
Gas pressure (Mpa)
0.4-0.6
0.4-0.6
0.6
0.6
0.6
0.6
0.6
Gas consumption (m3/min)
0.37
0.6
0.6
1.2
2.2
3
4.5
Motor power(kw)
1.75
3.22
4.8
8.5
8.5
8.5
8.5
Rated voltage (V)
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
380V/50Hz
Overall dimension (mm)
3790×650
×1550
3550×800
×1800
2800×1100
×1800
3550×1200
×1800
3800×1100
×1800
3650×1500
×1800
3800×1100
×1800
2200×1860
×2700
not include cleaning
2560×2350
×2750
not include cleaning
3100×2800
×2750
not include cleaning
