Psd Small Manual Cost-Effective Sugar Separation Centrifugal Plants
Jiangsu Huada Centrifuge Co., Ltd.- Rotating Speed Control：Frequency Inverter Control
- Operation：Manual Batch Operation
- Machine Control：PLC Control
- Centrifugal Type：Basket Centrifuge
- Moc：Stainless Steel
- Screen Touch：Optional
Base Info
- Model NO.：PSD
- Discharge：Pocket Top Lifting Discharge
- Application：Food Centrifuge
- Transport Package：Standard with Wooden Pallet and Poly Film Wrapping
- Trademark：Huada
- Origin：China
- HS Code：8421199090
- Production Capacity：100 Sets,Month
Description
ModelsPSD800 PSD1000 PSD1200 PSD1250 PSD1500 PSD1600 PSD1800 Basket Dia (mm) 800 1000 1200 1250 1500 1600 1800 Basket Volume (L) 120 200 330 400 600 800 910 Max. Load (kg) 150 250 410 500 800 1000 1100 Max. Rotating speed (r/min) 1200/1500 1100/1200 960/1050 1000/1200 850 850 780 Centrifuge Force 645/1006 680/806 670/968 700/1008 607 647 612 Motor (kW) 7.5 11 18.5 18.5/22 30 37 37 Dimension (L*W*H) (mm) 1720*1200*1300 2000*1400*1500 2550*1800*1780 2550*1800*1780 2600*2300*1800 3200*2400*2150 3300*2600*2100 Weight (kg) 1500 2500 3800 4000 6000 8500 10000
