Food Grade Stainless Steel Centrifugal Pump
Wenzhou Longwan Wanyuan Food Machinery Factory- Power Source：Electric
- Certification：CE, ISO9001
- Automatic Grade：Automatic
- Application：Milk, Cheese, Food, Dairy, Water
- Customized：Non-Customized
- Model Number：Ss304
Base Info
- Model NO.：LQ3A-30
- Usage：Dairy &Food&Water
- Fuel：Sanitary Centrifugal Pump
- Power：Electric
- Transport Package：Wooden Case
- Specification：SUS304
- Trademark：Wanyuan
- Origin：Wenzhou China
- Production Capacity：5000
Description
Basic Info.
Model NO. LQ3A-30 Usage Dairy &Food&Water Fuel Sanitary Centrifugal Pump Power Electric Transport Package Wooden Case Specification SUS304 Trademark Wanyuan Origin Wenzhou China Production Capacity 5000Product Description
Food Grade Stainless Steel Centrifugal PumpSpecifications
Stainless Steel Food Grade Sanitary Pump
1. Low noise
2. Can be disassembled and cleaned easily
3. Stable work
4. Best price
Sanitary beverage pump/sanitary water pump/sanitary centrifugal pump
1. Standard: 3A, ISO, DIN, SMS, IDF
2. Material: Stainless steel: (316, 304, 316L. 304L)
3. Motor: ABB
4. Suction lift: 8m, total lift: 19-34m
5. Flux: 5-30T
Sanitary beverage pump/sanitary water pump/sanitary centrifugal pump
Sanitary beverage pump features:
1. It is suitable for transporting high viscosity, ensity and any medium containing particle.
2. The rotational speed is low, generally keep already existing quality not changing, any physics and chemistry properties won't be changed.
3. LQ3A Stainless Steel stainless steel food grade Pump can be also called colloidal pump. All liquid flowing parts are made of stainless steel. It can transmit high viscosity, thickness and with particle medium.
4. High pressure of out let makes sure the long distance and high resisitance transportation with stable capacity used widely in health, food, chemical, industial areas.
5. Suitable temperature: -30 ° C to 200 ° C
Wenzhou wanyuan food machinery factory- - Sanitary beverage pump
Here below the sanitary beverage pump specification
| Model | Discharge Capacity per 100r (L) | Speed range (rpm) | Flow (L/H) | Motor power (kW) |
| LQ3A-6 | 6 | 200~500 | 650~1600 | 1.5 |
| LQ3A-8 | 8 | 200~500 | 850~2160 | 1.5 |
| LQ3A-12 | 12 | 200~500 | 1300~3200 | 2.2 |
| LQ3A-20 | 20 | 200~500 | 2100~5400 | 3 |
| LQ3A-30 | 30 | 200~400 | 3200~6400 | 4 |
| LQ3A-36 | 36 | 200~400 | 3800~7600 | 5.5 |
| LQ3A-52 | 52 | 200~400 | 5600~11000 | 5.5 |
| LQ3A-66 | 66 | 200~400 | 7100~14000 | 7.5 |
| LQ3A-78 | 78 | 200~400 | 9000~18000 | 7.5 |
| LQ3A-100 | 100 | 200~400 | 11000~22000 | 11 |
| LQ3A-135 | 135 | 200~400 | 15000~30000 | 11 |
