Small Scale Complete Pomegranate Juice Concentrate Process Plant
Shanghai Genyond Technology Co., Ltd.- Processing Material：Fruits
- Application：Beverage
- Customized：Customized
- Certification：CE, ISO9001
- Power Source：Electric
- Automatic Grade：Automatic
Base Info
- Model NO.：SG9
- Turn-Key Project：Automation
- Transport Package：Wooden Case
- Specification：gmp
- Trademark：Genyond
- Origin：Shanghai, China
- HS Code：84386000
- Production Capacity：2000sets,Year
Description
Main Technical Data: apple juice production lineModel CGF12125 CGF18186 CGF24248 CGF323210 CGF404012 CGF505012 CGF606015 CGF808020 Number of washing, filling and capping heads 12-12-5 18-18-6 24-24-8 32-32-10 40-40-12 50-50-12 60-60-15 80-80-20 Production capacity(600ml) (B/H) 2000-4000 5000-7000 8000-12000 12000-15000 16000-20000 20000-24000 25000-30000 35000-40000 suitable bottle specification(mm) φ=50-110=170 330-2250ml Washing pressure(kg/cm 2 ) 2-3 Motor power(kw) Main motor 2.2kw Main motor 2.2kw Main motor 3kw Main motor 5.5kw Main motor 7.5kw Main motor 11kw Main motor 15kw Main motor 19kw Overall dimensions (mm) 2400×1650 ×2500 2600×1920 ×2550 3100×2300 ×2800 3800×2800 ×2900 4600×2800 ×2900 5450×3300 ×2900 6500×4500 ×2900 76800×66400 ×2850 Weight (kg) 2500 3500 4500 6500 8500 9800 12800 15000
Pomegranate braking and seeds collection machine
Brief Introduction
Structure Mainly includes hopper, crushing device on the top and down, rotary screen, mixing axis, screw pump and rack etc.The machine is made of full stainless steel except the driving parts. The mixing axis is frequency-controlled.
Working Theory: The pomegranate is put into crushing device through hopper, and pressed by top crushing device(the distance between rollers is 20mm),then get into down crushing device, pressed again (the distance between rollers is 10mm).The seeds and peel of the pomegranate will be separated by separating device after two time pressing, the seeds will come out through the screen under the mixing of the axis, the peel will come out from down side.The seeds and juice will be sent to juice extractor through screw part,the price here doesn't include the extractor. The pressing rollers are flexible, whose distance can be adjusted well.
Output: 3500kg/h
Rotary Screen : 400mm
Rotary speed : 9.4rtm/min
Motor Power: 8 KW
Dimensions : 2105*886*1900MM
Net weight : 858 KG
Pomegranate braking and seeds collection machine
Brief Introduction
Structure Mainly includes hopper, crushing device on the top and down, rotary screen, mixing axis, screw pump and rack etc.The machine is made of full stainless steel except the driving parts. The mixing axis is frequency-controlled.
Working Theory: The pomegranate is put into crushing device through hopper, and pressed by top crushing device(the distance between rollers is 20mm),then get into down crushing device, pressed again (the distance between rollers is 10mm).The seeds and peel of the pomegranate will be separated by separating device after two time pressing, the seeds will come out through the screen under the mixing of the axis, the peel will come out from down side.The seeds and juice will be sent to juice extractor through screw part,the price here doesn't include the extractor. The pressing rollers are flexible, whose distance can be adjusted well.
Output: 3500kg/h
Rotary Screen : 400mm
Rotary speed : 9.4rtm/min
Motor Power: 8 KW
Dimensions : 2105*886*1900MM
Net weight : 858 KG
