• Model NO.：storage tank ss304
• Interior Construction：304 Stainless Steel, with #4 Finish
• Exterior Construction：304 Stainless Steel, with #2b Finish
• Insulation：Polyurethane, Min 2" Thick
• Vertical Agitation：Bottom Sweep, Bottom and Side Sweep, Side and Bott
• Manway：Top Entering, Hinged
• Inlet/Outlet Ports：Sanitary Clamp Connections
• Tank Bottom：Conical with 15 Degree Slope and Center Outlet
• Tank Top：Inverted Cone with 15 Degree Slope
• Clean in Place：CIP Device
• Heat Transfer Surface：Side and Bottom Stainless Steel Dimple Plate Rate
• Transport Package：Wooden Case
• Specification：132Gallon~5000Gallon
• Trademark：OEM
• Origin：China
• HS Code：847982
• Production Capacity：5000PCS Per Month

1,000 Gallon1,500 Gallon2,000 Gallon2,500 Gallon3,000 Gallon4,000 Gallon5,000 Gallon6,000 Gallon7,000 Gallon8,000 Gallon10,000 Gallon12,000 Gallon15,000 Gallon20,000 Gallon25,000 Gallon30,000 GallonCustom sizes and configurations are available.
customized / Standard Features of Insulated / Refrigerated / jacketed Storage Tanks:

• Interior Construction: 304 Stainless Steel, 9 Gauge/4mm thick, with #4 finish
• Exterior Construction: 304 Stainless Steel, 14 Gauge/2mm thick, with #4 finish, max. 90" outside diameter
• Insulation: Polyurethane, min 2" thick
• Agitation: Vertical, 3-Blade, 230/460 volt, 3 Phase
• Manway: Side Entering
• Inlet/Outlet Ports: Sanitary Clamp Connections
• Tank Bottom: 3/4"/ft. Sloped to a full drain side outlet
• Tank Top: Inverted cone with 15 degree slope
• Base: Silo Type

Optional Features of mixing Storage Tanks:

• Interior Construction: 304 Stainless Steel, 9 Gauge/4mm thick, with #2B finish, for applications in which a #4 polished finish is not required.
• Interior Construction: 316 Stainless Steel, 9 Gauge/4mm thick, with #4 finish
• Agitation: Horizontal, 3-Blade, 230/460 Volt, 3 Phase
• AGITATION: Both horizontal and vertical may be equipped with drive specified by customer
• Manway: Top entering, in addition to or in lieu of side manway
• Alcove: Stainless Steel Alcove
• Tank Bottom: Cone bottom with center outlet
• Legs: Adjustable stainless steel legs
• Level Indicating Device: Liquid level indicating pressure device with monitor
• Temperature Indicating Well: 1/2" dial type thermometer well
• Clean In Place: CIP Device
• Heat Transfer Surface: Side and bottom stainless steel dimple plate rated for 14.9 psi

Price for STAINLESS STEEL STORAGE TANKS
10,000Liter Stainless Steel Storage Tanks 5000 gallon for ink coating pigment dispersion
Stainless steel mixing tanks price is determinded by the tank capacity and the accessories on the tank.
We specialize in customized tanks - Let's talk about your request on the stainless steel mixing tanks
