Cheap 1t Capacity Steam Heating Blending Tank
Wenzhou Longwan Wanyuan Food Machinery Factory- Capacity：1000L
- Heating Mode：Steam Heating
- Layer Number：Three Layer
- Thickness：3,3,2mm (From Inner to Outer)
- Material：SUS304, Stainless Steel
- Transport Package：Wooden Case
Base Info
- Model NO.：MTS-1000
- Specification：SUS304
- Trademark：Wanyuan
- Origin：Wenzhou China
- HS Code：8479819000
- Production Capacity：5000
Description
Basic Info.
Model NO. MTS-1000 Specification SUS304 Trademark Wanyuan Origin Wenzhou China HS Code 8479819000 Production Capacity 5000Product Description
Cheap 1T capacity Steam Heating Blending TankBlending tank short description:
1. Capacity: 1000L
2. Heating mode: steam heating
3. Material: stainless steel
4. Layer number: tri-layer
5. Thickness: 3/3/2mm
6. Motor power: 2.2Kw
7. Mixing speed: 36rpm
Also our Blending tank can be customized, the following detail maybe you can refer:
1. Capacity: 50L-20000L
2. Material: SUS304/ SUS316
3. Thickness: can according to your products/ material
4. Mixing speed: 20rpm, 36rpm, 1780rpm, 2800rpm etc..
5. Agitator: with scraper/ without
Blending tank <mixing tanks> mainly made of stainless steel, used for mixing different liquid together.
Also, you can use this blending tanks to mix liquid and power to make a mixture.
Blending tanks can be with different mixing speed. Such as 36rpm, 60rpm fixed mixing speed. But due to some production reqeust, you may need the blending tanks with variable speed, such as 8 to 140rpm, 40 to 200rpm mixing speed, or 200 to 1000 rpm mixing speed. In special request, we can use VFD<Variable Frequency Drive> to meet your special mixing speed request.
Blending tank picture in factory:
Wenzhou wanyuan food machinery factory mainly produce stainless steel blending tanks for milk, juice, beverage, cosmetic, detergent as well as chemical product.
Wenzhou wanyuan food machinery factory--Blending tank
Our blending tank capacity can be 50L, 200L, 500L, 2000L or any other capacity you need.
The below is Mixing tank specifications:
| volume (L) | Dimension (D× h ) (mm) | Total height (mm) | Diameter Of inlet & outlet | Heat preservation layer (mm) |
| 500 | 840 × 1000 | 2250 | 38 | 60 |
| 600 | 920 × 1000 | 2300 | 38 | 60 |
| 700 | 990 × 1000 | 2300 | 38 | 60 |
| 800 | 950 × 1220 | 2500 | 38 | 60 |
| 900 | 1010 × 1220 | 2500 | 38 | 60 |
| 1000 | 1060 × 1220 | 2550 | 51 | 60 |
| 1500 | 1160 × 1500 | 2850 | 51 | 60 |
| 2000 | 1340 × 1500 | 2900 | 51 | 60 |
| 3000 | 1410 × 2000 | 3400 | 51 | 60 |
| 4000 | 1620 × 2000 | 3450 | 51 | 60 |
| 5000 | 1810 × 2000 | 3500 | 51 | 60 |
