• Model NO.：GYCS-1
• Turn-Key Project：Yes
• Material：Stainless Steel
• Capacity：as Customer Request
• Brand：Genyond
• Transport Package：Wooden Packing
• Specification：as customer capacity
• Trademark：GENYOND
• Origin：China
• HS Code：84198100
• Production Capacity：800 Sets Per Year

Basic Info.

Model NO. GYCS-1 Turn-Key Project Yes Material Stainless Steel Capacity as Customer Request Brand Genyond Transport Package Wooden Packing Specification as customer capacity Trademark GENYOND Origin China HS Code 84198100 Production Capacity 800 Sets Per Year

Product Description

Candy Bar Automatic Forming Line/Snicker Line/ Cereal Bar Line/Fruit Bar Line/Protein Bar Line/ Nougat Line/Halva Bar Line/ 3 Whatchamacallit candy bar making line   is designed to meet the fast growing market demand for bar products like Snicker, Nougat, Cereal Bar, Grains Bar, Energy Bar, Fruit Bar, Protein Bar, etc.
This line is perfect for both candy bars and bar products intend for diet and nutritional markets. And can also be used to produce everything from nougat or toffee layers, with or without nuts, to granola bars, etc.

Candy Bar Forming Line is available in four widths: 400, 600 and 800mm. All functions of the bar forming line are regulated by means of one or two PLC control cabinets which is very easy to operate and saves time. Option of incorporating a cooling tunnel for enhanced cooling of the product layers. High quality rollers designed to guarantee both precise forming and optimum cold transfer from the brine tank (Copeland Brand) to the product. The outstanding performance of the cooling equipment and system used for subsequent drying of product layers. Maximum efficiency and reliability and the option of varying cut dimensions, both in terms of length and width

MUESLI, CEREAL & CONFECTIONERY CHOCOLATE BARS PRODUCTION LINE can make all kinds of sugar line. It has all automatic continue produce technology, high production advanced technology. Coordinate with spray machine, it can produce all kinds of chocolate compound products.
PROCESSING CHART:
Cooking sugar - Mixing - Forming - Cooling - Longitudinal Cutting - Fanning - Transverse cutting - Enrobing - Cooling - Packing
Technical Parameters:

Main Machine	SINGLE ROLLER	COMPOND ROLLER	LONGITUDINAL  CUTTING MACHINE	TRANSVERSE  CUTTING MACHINE
Power	2.75KW	6.62KW	2.58KW	1.29KW
Dimensions	1200×1000×1400MM	1400*1340*2500MM	2520×1390×1206MM	2000×962×1900MM
Weight	800KGS	950KG	500KG	500KG
