• Model NO.：GJB2500-25
• Material：Stainless Steel 304
• Transport Package：Plywood Case
• Specification：CE
• Trademark：CHANGGUAN
• Origin：Changzhou
• HS Code：8479820090
• Production Capacity：300set,Year

Basic Info.

Model NO. GJB2500-25 Material Stainless Steel 304 Transport Package Plywood Case Specification CE Trademark CHANGGUAN Origin Changzhou HS Code 8479820090 Production Capacity 300set/Year

Product Description

Milk homogenizer
Homogenizer
Homogenizer is a kind of versatile equipment which can make liquid substance into high pressure spray or homogeneous and finer material. It is suitable for the homogenizing of liquid products whose viscosity is lower than 0.2Pa and whose temperature is lower than 80° C.

Principle of work
The equipment transports the processed material to homogenizing valve in high pressure by triple plunger pump.Pressure through an adjustable current-limiting gap process, the formation of loss of pressure expansion, explosion, shear, combined effect of high-speed collision, the particles and liquid droplets shatter into very small size, while creating an ideal solution or dispersion of emulsion. Product stability, consistency, mixed, and easy absorption, nutritional value, shelf life, flavor, color, security activities are realized in the homogeneous process.

Usages of homogenizer
It is widely used in food, dairy, beverage, pharmaceutical, fine chemicals and bio-technology and other fields of production, scientific research and technological development.
For milk,soybean milk,could make fat globule thin observably,make it easy to assimilate.It is good to increase the edible value.
For ice cream,make the liquid fine and loosen and improve internal quality.
For emulsion,colloid,juice,serosity,could avoid and decrease the separated layers of liquid material,improve the appearance of liquid material,and make it identical coloury liquid.
As transportation pump usage
It will come into high pressure by our machine.Powder will be made by dryness equipment.Our machine is important process of manufactorying powder.


Item	Model	Capacity(L/H)	Rate pressure(Mpa)	Max.working pressure(Mpa)	Power(Kw)	Weight(kg)	Size(cm)
	GJB500-25	500	25	20	5.5	670	100x75x110
	GJB1000-25	1000	25	20	7.5	670	100x75x110
	GJB1500-25	1500	25	20	7.5	720	100x75x110
	GJB1000-30	1000	25	20	11	720	100x75x110
