Ce&ISO Certified Automatic Chocolate Making Machine with Factory Price
Shanghai Target Industry Co., Ltd.- Certification：CE, ISO9001
- Power Source：Electric
- Process：Concentration and Dry
- Automatic Grade：Automatic
- Application：Chocolate
- Customized：Customized
Base Info
- Model NO.：CQ
- Capacity：0.5-2.5ton,Class
- Weight：1000-6200kg
- Power：9-28kw
- Transport Package：Wooden Case
- Specification：CE, ISO9001: 2008
- Trademark：tgmachine
- Origin：Shanghai
- HS Code：84381000
- Production Capacity：1 Set,2 Monthes
Description
Basic Info.
Model NO. CQ Capacity 0.5-2.5ton/Class Weight 1000-6200kg Power 9-28kw Transport Package Wooden Case Specification CE, ISO9001: 2008 Trademark tgmachine Origin Shanghai HS Code 84381000 Production Capacity 1 Set/2 MonthesProduct Description
Application:
The moulding line is for chocolate deposit forming. The whole process is fully automatic including depositing,mould plate vibrating,cooling,demoulding,conveying and plate heating.You can choose one head,two heads or three heads moulding line for different products.The line is suitable for pure chocolate,center filled chocolate,two color chocolate,four color chocolate,amber or agate chocolate,etc.
Technical Parameters:
| Model Project | Q110 | Q111 | Q112 | Q113 |
| Capacity ton/class | 0.5~1.5 | 0.8~2.5 | 0.8~2.5 | 0.8~2.5 |
| Total power lncluding freezer | 9 | 21 | 23 | 28 |
| Refrigeration quantity kcal/hour | Don't have | 21800 | 21800 | 21800 |
| Mould plate size mm | 275×175×30 | 280×200×30 | 280×200×30 | 280×200×30 |
| Mould plate quantity (m) | 270 | 270 | 380 | 420 |
| Weight (kg) | 1000 | 4800 | 5800 | 6200 |
| Outside dimensions mm | 3600×725×1560 | 17010×1010×1330 | 17060×1005×1870 | 18600×1200×2400 |
