• Model NO.：BH Series
• HS Code：8419500090
• Production Capacity：300 PCS,Month

BS100Cross  Reference M10B/M10MHeight,   H  [mm] 10841084Width,   W  [mm] 470470Min.  standard  length,   L  [mm]700700Max.  standard  length,   L  [mm] 23002300Vertical  port  distance,   VC  [mm]719719Horizontal  port  distance,   HC  [mm]225225Max.  temperature  [° C]180180Max.  pressure  [barg]1016Flange  sizeDN100/4"DN100/4"Max.   flow  rate  [kg/s]50 GasketMaterialApplicable TempApplicable fluidsNBR  -15C to +135CWater, sea water, Mineral oil, salinous waterEPDM  -25C to +180CHot water, Steam, Acid, AlkaliF26  -55C to +230CAcid, AlkaliFTP  0C to +160CHigh Concentrated acid, Alkali, High temperature oil, Steam
