High Quality Automatic Central-Filled Soft Milk Candy Production Line
Shanghai Target Industry Co., Ltd.- Certification：CE, ISO9001
- Power Source：Electric
- Process：Thermal Processing
- Automatic Grade：Automatic
- Application：Candy
- Customized：Customized
Base Info
- Model NO.：T300
- Capacity：300kg,H
- Speed：1000PCS,Min
- Dimension：1600*1200*2100mm
- Voltage：380V
- Material：Stainless Steel
- Weight：8000kg
- Power：18kw
- Transport Package：Wooden Case
- Specification：CE, ISO9001: 2000
- Trademark：tgmachine
- Origin：Shanghai
- HS Code：84382000
- Production Capacity：1 Set,2 Months
Description
Basic Info.
Model NO. T300 Capacity 300kg/H Speed 1000PCS/Min Dimension 1600*1200*2100mm Voltage 380V Material Stainless Steel Weight 8000kg Power 18kw Transport Package Wooden Case Specification CE, ISO9001: 2000 Trademark tgmachine Origin Shanghai HS Code 84382000 Production Capacity 1 Set/2 MonthsProduct Description
The processing line is an advanced one for making various kinds of soft candies, such as central-filling milk candies, soft candies and etc.. It is also an ideal equipment which can produce out good quality products with the saving of both the manpower and the space occupied.
TECHNICAL SPECIFICATIONS:
Model | T300 |
Production capacity ( kg/h) | 300 |
Rated output speed (pcs/min) | 1000 |
Weight of each candy (g) | Shell: 7g(max.) Central-filling:2g(max) |
Steam consumption (kg/h) Steam pressure (Mpa) | 400 0.2~0.6 |
Electric power needed | 34kw/380V |
Compressed air consumption Compressed air pressure | 25m3/min 0.4-0.6 Mpa |
Conditions needed for the cooling system: 1.Room temperature(ºC) 2. Humidity (%) | 20~25 55 |
Length of the whole line (m) | 16m |
Gross weight ( Kgs) | Approx.8000 |
PROCESS FLOWING LAYOUT CHART:
DissolvingàTransporting àStorage àContinuous cooking and aeratingà Cooling à Drying and aging à Extruding and fillingà Rope sizing à Cooling conveyor à Forming à Swing dischargerà Packing
