• Model NO.：GT7C 360
• Capacity：500L
• Heating Mode：Electric Heating
• Structure：Vertical Type
• Working Pressure of Autoclave：0.3MPa
• Designed Pressure of Autoclave：0.35MPa
• Design Temperature：147 Degree C
• Working Temperature：121 Degree C
• Usage：Canned Food, Glass Jar, Pouch
• Transport Package：Wooden Case
• Specification：SUS304
• Trademark：Wanyuan
• Origin：Wenzhou China
• HS Code：8438800000
• Production Capacity：5000

Basic Info.

Model NO. GT7C 360 Capacity 500L Heating Mode Electric Heating Structure Vertical Type Working Pressure of Autoclave 0.3MPa Designed Pressure of Autoclave 0.35MPa Design Temperature 147 Degree C Working Temperature 121 Degree C Usage Canned Food, Glass Jar, Pouch Transport Package Wooden Case Specification SUS304 Trademark Wanyuan Origin Wenzhou China HS Code 8438800000 Production Capacity 5000

Product Description

Model DN800*1000 vertical Autoclave sterilizer retort

Name: Autoclave sterilizer retort

Characteristics of the retort:
1. Vertical type,
2. Small scale, Small occupation space,
3. Use electric heating, the cost is not high,
4. Easy operation, high safety

----wanyuan Brand Electric heating autoclave(sterilizer)
Please used for health &sanitation.
Vertical autoclave(electric heating sterilizer)
Autoclave, it's used for beverage &food industry.
1. It is small scale electric autoclave.
2. Small land area, suited in Lab.
3. The working temperature range: 100-135C.
4. The Max temperature: 143C.
5. With control box, temperature meter, pressure meter, safe valve etc.
6. Made of stainless steel 304, outer and inner polishing to easy cleaning.
7. Electric power

Wenzhou Wanyuan Food Mechanical Fatory
Model DN800*1000 vertical Autoclave sterilizer retort

Here below the autocalve sterilizer retort specification:

Model	GT7C360
Inner Dia	DN800*1000
Sterilization baskets	Can be customized
Capacity	500L
Max Working Pressure	0.3 Mpa
Max Working Temperature	143 degree
Equipment Weight	508Kg
Equipment Dimensio	1585*1280*2223mm
