• Model NO.：KQ Series
• Name：Food Grade Sanitary Chemical Electric Heating Jack
• Material：Stainless Steel 304,316
• Capacity：100L -10000L
• Motor Brand：Siemens ,ABB ,China Brand
• Voltage ,Hz,Phase：Make It to Your Order .
• Agitator Speed：36rpm, 48rpm, 960rpm,2900rpm
• Heating and Mixing Tank：for Heating and Mixing Liquid, Liquid and Powder
• Storage Tank：Aseptic Storage Tank with Manhole
• Surface Treatment：Polished
• Delivery：10 Days
• Packing：Wooden Box
• OEM：Yes
• Factory：Shanghai China
• MOQ：1set
• Warranty：1 Set
• Transport Package：Standard Export Wooden Box
• Specification：ISO
• Trademark：KQ
• Origin：Shanghai China
• HS Code：8479820090
• Production Capacity：200L To30000L

Basic Info.

Model NO. KQ Series Name Food Grade Sanitary Chemical Electric Heating Jack Material Stainless Steel 304/316 Capacity 100L -10000L Motor Brand Siemens /ABB /China Brand Voltage ,Hz,Phase Make It to Your Order . Agitator Speed 36rpm, 48rpm, 960rpm,2900rpm Heating and Mixing Tank for Heating and Mixing Liquid, Liquid and Powder Storage Tank Aseptic Storage Tank with Manhole Surface Treatment Polished Delivery 10 Days Packing Wooden Box OEM Yes Factory Shanghai China MOQ 1set Warranty 1 Set Transport Package Standard Export Wooden Box Specification ISO Trademark KQ Origin Shanghai China HS Code 8479820090 Production Capacity 200L To30000L

Product Description

Food Grade Sanitary Chemical Electric Heating Jacketed Movable Mixing Vat Price

1

sugar mixing tank

TankCapacity(L)	200, SS304	300, SS304	500, SS304	1000,SS304
REV	36r/min	36r/min	36r/min	36r/min
Electric motor of the agitator	0.55KW,380v,50hz	0.75KW,380v,50hz	0.75KW,380v,50hz	1.1KW,380v,50hz
Heating Area(M2)	0.9	1.1	1.9	4.5
Material Input/output(DN MM)	38	38	38	50
OUTSIDE DEMENSION(L*W*H)MM	900*900*1600	1000*1000*1500	1100*1100*1700	1400*1400*1750
GROSS WEIGHT(KGS)	150	200	300	450

Material: Ss304
* Type: With Jacket and insulation
* Internal shell thickness: 3 mm
* Jacket thickness: 3 mm
*PU INSULATION WALL: 50MM
* Outer shell thickness: 1.5 mm
* Appearance: Ellipsoidal head top and down manhole and pipe will be as the picture you sent to us
* Accessories:


Food Grade Sanitary Chemical Electric Heating Jacketed Movable Mixing Vat Price .
