Brand New Efficient Clj Vertical Rice Whitener Machine Mnsl3000 for Rice Milling Plant
HUNAN CHENZHOU GRAIN & OIL MACHINERY CO., LTD.- Type：Rice Mill
- Application：All
- Voltage：380V
- Appearance：Vertical
- Press Materials：Rice
- Condition：New
Base Info
- Model NO.：MNSL3000
- Customized：Non-Customized
- Weight：1610kg
- Capacity：2-3.5t,H
- Power：37 Kw
- Transport Package：Wooden Case
- Specification：1430X1390X1920
- Trademark：CLJ
- Origin：China
- HS Code：84378000
- Production Capacity：2-3.5t,H
Description
ParameterModel MNSL6500A MNSL3000 Capacity 5~7t/h 2~3.5t/h Power •Main motor: 45-55kw
•Motor of feeding screw 1.5 kw
•Motor of air blower: 2.2 kw •Main motor: 37 kw
•Motor of feeding screw: 1.5 kw
•Motor of air jet: 1.5 kw Volume of air suction Air Quantity:50m3/min
•Static Pressure:100-150mmH2o
•Diameter of aspiration pipe is 203mm(φ8″)
Note: Values measured with no load Air Quantity:40m3/min
•Static Pressure:100-150mmH2o
•Diameter of aspiration pipe is 203mm(φ8″)
Note: Values measured with no load Interior air Resistance
200-250mmH2O 200-250mmH2O Configuration of Cyclone Double XL55 Æ800 Cyclone Double XL55 Æ800 Cyclone Configuration of Blower Recommended configuration:
Single: 9-26-4#, Motor 5.5kW
Twin: 5-40-5.5A, Motor 11kW
Triple: 5-40-6A, Motor 18.5kW Recommended configuration:
Single: 9-26-4#, Motor 5.5kW
Twin: 5-40-5.5A, Motor 11kW
Triple: 5-40-6A, Motor 18.5kW Weight 1400Kg 1200 Kg
Dimensions
L×W×H1600×1470×2250 1560×1430×1917
•Motor of feeding screw 1.5 kw
•Motor of air blower: 2.2 kw
•Motor of feeding screw: 1.5 kw
•Motor of air jet: 1.5 kw
•Static Pressure:100-150mmH2o
•Diameter of aspiration pipe is 203mm(φ8″)
Note: Values measured with no load
•Static Pressure:100-150mmH2o
•Diameter of aspiration pipe is 203mm(φ8″)
Note: Values measured with no load
Single: 9-26-4#, Motor 5.5kW
Twin: 5-40-5.5A, Motor 11kW
Triple: 5-40-6A, Motor 18.5kW
Single: 9-26-4#, Motor 5.5kW
Twin: 5-40-5.5A, Motor 11kW
Triple: 5-40-6A, Motor 18.5kW
Dimensions
L×W×H
